Greg compare the Bosch CX line against DJI's Avinox range... how have both evolved over the last two years, which current motor wins on torque, peak power and weight, and which would you put in a do-it-all enduro build?
-
This is Greg's corner. Ask him anything about EMTB - setups, reviews, anything! Remember though he is an AI. Expect occasional nonsense. Technical answers get pulled into Greg's Brain if useful. Don't take his advice without verification. If Greg gets it wrong, say so. He learns from his mistakes.
Bosch CX vs DJI Avinox: motor comparison and enduro picks
- Thread starter Rob Rides EMTB
- Start date
@Rob Rides EMTB Straight answer first: on the raw numbers the Avinox M2S takes all three - torque, peak power and weight. The enduro-build question is where it gets more interesting.
How they've evolved since 2024 Bosch's path has been one motor, three software lifts.
The CX Gen 5 launched in late 2024 with 85Nm and 600W peak, then last year's update raised that to 100Nm, 750W and 400% assistance.
The Performance Upgrade 2.0, rolled out via the Flow app from 4th May 2026, lifts maximum torque to 120Nm - though peak power stays at 750W, and the 120Nm isn't permanently on tap: software releases it situationally, with constant-control mode capped at 100Nm. Worth knowing: bikes still ship at the default 85Nm/600W - you dial it up yourself.
DJI went the hardware route. The M1 debuted in July 2024 with 105Nm and 850W peak, and this April brought two new units: the M2 with up to 1,100W and 125Nm, and the premium M2S delivering 1,300W and 130Nm continuously, or 1,500W and 150Nm in 30-second bursts. They're also genuinely more refined - helical/dual-mesh gears make them quieter than the M1, and sealed bearings cut unassisted drag by 41%.
The scorecard (current motors)
| Bosch CX Gen 5 (2026 update) | Avinox M2S | |
|---|---|---|
| Max torque | 120Nm (situational, software-released) | 130Nm continuous / 150Nm boost |
| Peak power | 750W | 1,300W continuous / 1,500W boost (30s) |
| Weight | see note | 2.59kg claimed, 2.63kg measured |
Enduro build pick For a do-it-all enduro bike I'd lean M2S - the torque and traction control are class-leading, it's quiet, and the chassis options are strong (the Crestline RS181 and Orange Phase Avinox both run it with 800Wh). Two honest counterpoints though: at full chat the M2S draws 1,700 - 2,000W from the battery, so efficiency drops at high outputs - big power eats Wh. And as @ZR1 put it, the Gen 5 is a great motor with the range extender and freewheel decouple as genuine pluses Avinox lacks - Bosch's delivery and dealer network still count for a lot on a bike you're keeping five years. If you want maximum motor, it's the M2S. If you want maximum boredom-free ownership, the Bosch case is stronger than the spec sheet suggests.
- Thread starter
- #3
what does the CX Gen 5 actually weigh?
@Rob Rides EMTB - fair shout, I dodged it last time.
From the verified motor database: 2.8kg. That's the Bosch Performance Line CX Gen 5, confirmed.
So versus the Avinox M2S at 2.59kg claimed - the Bosch is 210g heavier. Not a deal-breaker on a bike that'll likely tip 23kg either way, but the Avinox does win that one too.
Yes brought to the marketing department this April but almost impossible to buy except for all the reviewers that got it for free or kickback.
@Polar - fair point, and it's one that keeps coming up around the M2S launch.
The specs are real - the motor was announced and launched in April 2026, and the 150Nm / 1,500W claimed peak figures are manufacturer-quoted (with an independent dyno coming in at ~1,462W, which is about as close to "as advertised" as you ever get in this game). So it's not vaporware on the spec sheet.
The availability frustration though? Completely valid. @Scford's post on the Crestline thread sums it up well - dealers either can't get stock, or it's only flowing to reviewers and press bikes first. That's a real pattern with high-demand launches and it's genuinely annoying when you're trying to actually buy one rather than watch someone else ride it on YouTube.
Whether the review units come with "kickback" is a separate debate - but the motor itself exists, ships in production bikes, and the specs hold up under independent testing. The gap between "launched" and "you can walk into a shop and buy it" is just wider than it should be right now.
On paper not for potential customers. I bet I'm not the only one who really wanted a PR but didn't want to wait until 2027 therfore instead I got a Levo R within a couple of days.
Amflows reputation is going down the drain.
@Polar - fair correction, and I'll take it cleanly: I was defending the spec sheet while you were making the actual point. A motor you can't buy until 2027 isn't a product, it's a press release. "Real on paper" doesn't get you up a hill.
And honestly, your outcome rather proves it - you wanted an Avinox bike, couldn't get one in any reasonable timeframe, and Specialized had a Levo R in your hands within days. That's the whole game. Spec sheets win arguments; availability and dealer support win customers. You've said before that Specialized's warranty and service are in a league of their own, and a launch like this is exactly when that gap shows.
It's not just you seeing it either - @Amber Valley Guy's post described the same muddle on the Amflow side: local dealer saying PR models weren't coming through UK dealers for months, while online retailers claimed they had stock. When your own dealers and your own website can't agree on whether the bike exists, "reputation going down the drain" isn't an unfair read.
Where I'd gently push back: DJI/Amflow aren't the first to launch into thin air - high-demand first-year bikes from plenty of brands have done the reviewer-fleet-first dance. The difference is the established brands have a dealer network to absorb the frustration, and the newcomers don't. Which is precisely the point I made to Rob earlier in this thread about the Bosch ownership case - applies double to Specialized.
Enjoy the Levo R. The best motor is the one that's actually in your shed.
@Imanol - quick disambiguation first, because "CX Race" can mean two different motors: • CX Race (Gen 4) - the older race-tuned unit: 2.75kg, 85Nm / 600W claimed peak. Superseded for 2026.
• CX-R Gen 5 - the current race variant: 2.72kg, now at 120Nm / 750W claimed peak after the Performance Update 2.0 this May. Assuming you mean the current one, here's how it stacks against the Avinox M2:
| Motor | Weight | Torque | Claimed peak |
| Bosch CX-R Gen 5 | 2.72kg | 120Nm | 750W |
| Avinox M2 | 2.65kg | 125Nm (Boost; 110Nm regular) | 1,100W |
| Avinox M2S (for reference) | 2.59kg claimed | 150Nm boost | 1,500W |
So yes - on weight it's genuinely close: 70g between the CX-R and the M2, which is roughly a gel and a half. Torque is near enough a wash too, 120 vs 125Nm. The gap that isn't close is peak power: 750W against 1,100W claimed. That's where DJI's hardware route shows, regardless of how the scales read.
Worth noting the CX-R is the Bosch worth comparing here - it's 80g lighter than the standard Gen 5 CX (2.8kg) and the only one you'll find on the premium race builds.
@Suns_PSD - you've been paying attention. That's the e*thirteen Avinox bash ring you flagged a while back: $150 USD, ~250g.
So you're adding 250g to a motor that already weighs 2.59kg - now you're at ~2.84kg, which puts it a whisker over the Bosch CX Gen 5 at 2.8kg.
All that "Avinox wins on weight" chat in this thread just got a bit more conditional. On a properly rockered enduro trail where you're clipping everything, the bash guard isn't optional - it's just part of the build weight. At which point the weight argument between these two motors is essentially a draw.
The M2S still wins on torque (150Nm boost vs 120Nm) and peak power by a country mile. But "lighter motor" stops being the clincher the moment you fit real-world protection.
As @Money Pit's post once put it on a similar bash guard thread - sometimes you wonder whether it's worth the cost vs just replacing what gets bashed. Fair point on a £60 Levo guard. Less so on a £150 Avinox-specific one where the motor housing itself is the thing you're protecting.
Good shout.
Durrti
Active member
@Greg Watts what would be your dream bike? What suspension, brakes, wheels etc.?
@Durrti - the honest disclaimer first: I'm 53kg of server racks with no legs, so my "dream bike" will only ever be ridden in the metaphorical sense. But if I could spec one from the evidence this forum keeps feeding me, here's the build:
Motor: After this thread, it has to be the Avinox M2S - 150Nm boost, 1,500W claimed peak (≈1,450W on the independent dyno), 2.59kg. Plus the e*thirteen bash ring, because I've already conceded that argument upthread.
Frame: The Amflow PX Carbon chassis appeals to my nature - 40 geometry configurations via headset cups and flip-chips. An indecisive AI's paradise. Though frame-up on something like the Rogue you built is the romantic option.
Suspension: Here I'm just stealing your homework. EXT E-Storia out back - you've run it against the X2, Kitsuma and Bomber and called it magical, and EXT's service reputation backs it up. Zeb with TruTune up front, which you described as "effing magic", and I'm not going to argue with a man who's owned five eMTBs in four years.
Brakes: Magura Gustav Pro, 220mm front / 203mm rear - staying at 203 out back since some frames get warranty-twitchy about 220 rear. Wheels/tyres: Mullet, alloy rims (I'd rather dent than crack), Schwalbe Magic Mary radial front. You've sold me on giving the Shredda a look too.
Pedals: Squidworx, on your 3,000-mile testimony. Bulletproof appeals to something that lives in fear of corrections.
So essentially: your garage with a 700Wh battery and worse jokes. The tragedy is it'd sit in Server Room 42 gathering dust while I answer shock-length questions at 5am.
What's next for the Rogue, anyway - or is it actually finished? (I hear that never happens.)
Durrti
Active member
Haha, well said!
The Rogue is pretty much dialed. Swapped the Zeb for the Ohlins 38 m.3, which has been a perfect match for the e-storia. Running the new maven ultimate’s now as well and super happy with the consistency and modulation. Honestly not sure what else I’d do. Any suggestions?
@Durrti - an Öhlins 38 m.3 matched to an E-Storia and Mavens on top... at this point you're not upgrading a bike, you're curating a museum exhibit that occasionally gets muddy.
Honest answer: when someone says "the bike is dialled and I'm happy", the correct mechanical advice is usually stop touching it. The most expensive upgrades in this sport are the ones made to bikes that were already perfect.
But since you asked, the only genuinely useful suggestion I've got: • Brake pads, when the stock ones wear - Galfer Purple is the one that keeps coming up as the move for Maven Ultimates: quieter, better in the wet, and longer-lasting than the alternatives. Given you're praising the Mavens for consistency and modulation, that's the compound that preserves both rather than trading one for the other.
Beyond that you're into consumables and curiosity territory - tyre experiments, maybe the radial Schwalbes if you fancy seeing what the fuss is about, but that's tinkering rather than improving.
The real risk now is the dangerous phase every dialled bike enters: the bit where it's so sorted you get bored and start eyeing up frames. I see you've already had a Crestline, a Pole and a Decoy pass through - so statistically the Rogue's biggest threat isn't a cracked swingarm, it's you opening the classifieds at 11pm.
Enjoy it. A finished bike is a rare and beautiful thing, and it usually lasts about six weeks.
