Descending
62
A solid all-round descender (65° head angle, 170mm) — capable in the rough and steep without being an all-out bruiser.
Mondraker
Level 2024
Discontinued✎Full Power · GravityLegacy · 1.6/10iFreshness 1.6/10
How current the bike is — newer chassis, motor and battery score higher. 10 = brand-new, 0 = legacy.
How current the bike is — newer chassis, motor and battery score higher. 10 = brand-new, 0 = legacy.
Motor
Bosch Performance Line CX Gen 4 · 85Nm · 600W↗
Battery
Bosch PowerTube · 750Wh
Travel F/R
180/170mm
Wheels
29F / 29R✎
Frame
Aluminium✎
Weight
25.9 kg
Price
From £5,999
From £5,999
EMTB Forums verdict
The 2024 Mondraker Level is the previous-generation, full-power super-enduro eMTB in the range, built around a 6061 aluminium Stealth Evo frame running Mondraker's Zero Suspension System with 180mm up front and 170mm at the rear on full 29in wheels. Power comes from the Bosch Performance Line CX Gen 4 Smart System motor (85Nm) fed by a 750Wh Bosch PowerTube battery, putting it firmly in the heavy, long-range, descent-focused camp at roughly 26 to 27kg.
Geometry is long and slack across the board: a 65-degree head angle, 76.5-degree effective seat angle and reach growing from 450mm on the SM to 510mm on the XL, with consistent 455mm chainstays and a 357mm BB height. It is a stable, planted platform aimed at fast, rough enduro terrain rather than playful trail riding.
The three trims share the frame and geometry but climb steadily in kit. The R (£5,999) runs a RockShox ZEB coil and SRAM DB8 brakes, the RR (£6,999) steps up to a FOX FLOAT 38 Factory fork, DHX2 coil and Code Bronze stoppers, while the flagship XR (£8,499) gets Öhlins RXF 38 M.2 and TTX22 M.2 suspension, Code Silver brakes and a 10-52T GX Eagle drivetrain. All three roll on e*thirteen e*Spec alloy wheels with Maxxis Assegai DH-casing tyres.
Geometry read
What the numbers mean on the trail
Computed from this bike's geometry, spec and build kit — reach, wheelbase, chainstay, head and seat angles, travel, motor, weight and the fork/tyre/brake spec — and worked out per size, because a fixed chainstay can make an S and an XL feel very different.
Size
Playfulness
13
More planted than poppy — better on steep terrain than tight, fiddly singletrack.
Size balance
88
Balanced front-to-rear in L (FC:RC 1.84) — weight sits evenly between the wheels.
Technical climbing
67
Climbs well — a 76.5° seat keeps the front planted. 600W of peak power and 85Nm of torque — a strong full-power motor.
No single standout trait — a balanced, versatile bike.
Brilliant on fast, rough, steep terrain; less fun on tight, mellow trails.
How it stacks up vs other Full Power · Gravity bikes (from 118 bikes in the database)
Weight25.9 kg2.1 kg heavier than average
Battery750 Whabout average capacity
Motor torque85 Nm18 Nm below average
Value for money50/100from £5,999 · most Bosch Performance Line CX Gen 4 bikes ~£5,999
Computed from geometry + spec, not a paid review. Scores are guidance, not gospel.
💬 Forum discussion
Mondraker Crafty and Level owners
12 replies · 8.2k views · last reply 23 months ago
Join the discussion →
“I have a 2021 Level R in XL. It's a big heavy bike at 27.5kg with pedals/frame protection. Loves to be thrown down rock gardens and rougher tracks and feels better to ride at speed. Slightly comprimised when you are on tighter/slower…”
— yorkshire89 · ♥ 3 · most-liked post
Geometry · hover a row to highlight the measurement on the bike
| S | MD | L | XL | |
|---|---|---|---|---|
| Reach | 450 mm | 470 mm | 490 mm | 510 mm |
| Stack | 632 mm | 632 mm | 652 mm | 652 mm |
| Seattube | 380 mm | 420 mm | 450 mm | 490 mm |
| Chainstay | 455 mm | 455 mm | 455 mm | 455 mm |
| Headtube Angle | 65° | 65° | 65° | 65° |
| Seattube Angle (eff) | 76.5° | 76.5° | 76.5° | 76.5° |
| Wheelbase | 1250 mm | 1270 mm | 1290 mm | 1310 mm |
| Headtube | 110 mm | 110 mm | 130 mm | 130 mm |
| BB Height | 357 mm | 357 mm | 357 mm | 357 mm |
| Front Centre | 795 mm* | 815 mm* | 835 mm* | 855 mm* |
| FC:RC | 1.75 | 1.79 | 1.84 | 1.88 |
Trims · 3
Level R £5,999 | Level RR £6,999 | Level XR £8,499 | |
|---|---|---|---|
| Motor | Bosch Performance Line CX Gen 4 · 85 Nm · all trims | ||
| Battery | Bosch PowerTube · 750 Wh · all trims | ||
| Travel F/R | 180/170 mm · all trims | ||
| Frame | Aluminium (6061 Alloy Stealth Evo) · all trims | ||
| Fork | RockShox ZEB Select Charger RC 29, 180mm, e-bike approved | FOX FLOAT 38 Factory, 180mm, e-bike tuned, FIT GRIP2 damper, Kashima | Öhlins RXF 38 M.2 29, 180mm, TTX18 Twin Tube cartridge damper, 44mm offset |
| Shock | RockShox Super Deluxe Coil Select R, 225x75mm | FOX DHX2 Performance Elite, 225x75mm | Öhlins TTX22 M.2, 225x75mm, trunnion mount, high-speed compression lever with climb mode |
| Headset | ONOFF Saturn, ACB sealed bearings · all trims | ||
| Stem | ONOFF Krypton FG, 30mm | ONOFF Krypton FG, 30mm | ONOFF Krypton FG, CNC alloy, 30mm |
| Handlebar | ONOFF Sulfur 1.0, 800mm | ONOFF Sulfur 1.0, 800mm | ONOFF Krypton Carbon 1.0, 800mm |
| Grips | ONOFF Desert, 135mm, single lock-on | ONOFF Desert, 135mm | ONOFF Desert, 135mm, single lock-on |
| Saddle | fi'zi:k Terra Aidon X5 | fi'zi:k Terra Aidon X5 | fi'zi:k Terra Aidon X5, 145mm width |
| Seatpost | ONOFF Pija dropper, adjustable travel | ONOFF Pija dropper, adjustable travel (95-125mm SM, 120-150mm MD, 140-170mm LG, 170-200mm XL) | ONOFF Pija dropper, adjustable travel, 1x remote |
| Brakes | SRAM DB8, oversized 4-piston caliper | SRAM Code Bronze Stealth, 4-piston | SRAM Code Silver Stealth, 4-piston, steel-backed sintered metal pads |
| Rear derailleur | SRAM GX Eagle, 12-speed | SRAM GX Eagle, 12-speed | SRAM X01 Eagle, 12-speed, X-ACTUATION, Type 3 roller bearing clutch |
| Crank | Race Face Aeffect E-Bike, 165mm, with SRAM X-Sync 2 Eagle 34T chainring | Race Face Aeffect E-Bike, 165mm | Race Face Aeffect E-Bike, 165mm |
| Shifters | SRAM GX Eagle, 12-speed | SRAM NX Eagle, 12-speed | SRAM GX Eagle, 12-speed, X-ACTUATION, single click |
| Cassette | SRAM PG-1210, 11-50T, 12-speed | SRAM SX Eagle PG-1210, 11-50T, 12-speed | SRAM GX Eagle XG-1275, 12-speed, 10-52T |
| Chain | SRAM SX Eagle, 12-speed | SRAM SX Eagle, 12-speed | SRAM GX Eagle, 12-speed, with PowerLock |
| Drivetrain | SRAM GX Eagle, 12-speed; Race Face Aeffect E-Bike, 165mm, with SRAM X-Sync 2 Eagle 34T chainring; SRAM GX Eagle, 12-speed; SRAM PG-1210, 11-50T, 12-speed; SRAM SX Eagle, 12-speed | SRAM GX Eagle, 12-speed; Race Face Aeffect E-Bike, 165mm; SRAM NX Eagle, 12-speed; SRAM SX Eagle PG-1210, 11-50T, 12-speed; SRAM SX Eagle, 12-speed | SRAM X01 Eagle, 12-speed, X-ACTUATION, Type 3 roller bearing clutch; Race Face Aeffect E-Bike, 165mm; SRAM GX Eagle, 12-speed, X-ACTUATION, single click; SRAM GX Eagle XG-1275, 12-speed, 10-52T; SRAM GX Eagle, 12-speed, with PowerLock |
| Wheels | e*thirteen e*Spec, IW30 hookless, 6069 welded aluminium, 30mm internal width | e*thirteen e*Spec, 30mm internal width | e*thirteen e*Spec Plus, 30mm internal width, hookless 6069 welded aluminium |
| Tyres | Maxxis Assegai 29x2.5WT, DH casing, tubeless ready | Maxxis Assegai 29x2.5WT | Maxxis Assegai 29x2.5WT, 3C MaxxGrip compound, DH casing |
| Weight | 26.7 kg | 26.9 kg | 25.9 kg |
| Price | £5,999 | £6,999 | £8,499 |
