Descending
58
A solid all-round descender (65.5° head angle, 150mm) — capable in the rough and steep without being an all-out bruiser.
Mondraker
Chaser 2024
Discontinued✎Full Power · TrailLegacy · 1.6/10iFreshness 1.6/10
How current the bike is — newer chassis, motor and battery score higher. 10 = brand-new, 0 = legacy.
How current the bike is — newer chassis, motor and battery score higher. 10 = brand-new, 0 = legacy.
Motor
Bosch Performance Line CX Gen 4 · 85Nm · 600W↗
Battery
Bosch PowerTube 750 · 750Wh
Travel F/R
160/150mm
Wheels
29F / 29R✎
Frame
Aluminium
Weight
24.9 kg
Price
£5,220
From £5,220
EMTB Forums verdict
The 2024 Mondraker Chaser is an aluminium all-mountain eMTB built around the Bosch Performance Line CX (Gen 4, Smart System) motor with up to 85Nm and an internal Bosch PowerTube battery, in a 6061 Stealth Evo frame using Mondraker's Zero Suspension System and signature Forward Geometry. All sizes share a slack 65.5 degree head angle, a steep 76 degree effective seat angle, long 455mm chainstays and notably long reach for the size (450mm on the S rising to 510mm on the XL), spread across four sizes from S to XL on full 29in wheels.
The range splits into a genuine trail build and two crossover builds. The Chaser R is the pick for off-road riding: 160mm Fox 36 Rhythm fork, 150mm of rear travel through a Fox Float EVOL Performance shock, a 750Wh battery, Mavic E-Deemax wheels, Maxxis Rekon 2.6 tyres, SRAM GX Eagle and an Onoff Pija dropper, with a claimed 24.9kg. The Chaser RX (140mm rear, RockShox 35 Silver fork, 750Wh, Kiox 500 display) and Chaser X (140mm rear, RockShox Recon fork, 625Wh removable battery, rigid Onoff seatpost) are urban-cross oriented, shipping with lights, mudguards, a rear rack and a kickstand and rolling on faster Maxxis Ikon 2.6 tyres, both at a claimed 26.5kg.
This was a 2024 model and is now discontinued, so it is found at heavy clearance discounts. Mondraker's recommended retail prices were around 5,999 euros for the Chaser R and RX and 4,999 euros for the Chaser X; UK pricing was thinner, with the RX listed at an RRP of 5,220 pounds. Note that the brakes are SRAM DB8 four-piston with 200mm rotors front and rear across every trim, and the all-alloy frame keeps weights on the heavier side for the category.
Geometry read
What the numbers mean on the trail
Computed from this bike's geometry, spec and build kit — reach, wheelbase, chainstay, head and seat angles, travel, motor, weight and the fork/tyre/brake spec — and worked out per size, because a fixed chainstay can make an S and an XL feel very different.
Size
Playfulness
30
More planted than poppy — better on steep terrain than tight, fiddly singletrack.
Size balance
98
Rear-long with a planted front in L (FC:RC 1.78) — easy to weight the front and quick to turn, though it can feel light at the back at real speed.
Technical climbing
75
Bosch Performance Line CX Gen 4 and a steep 76° seat angle keep the weight planted over the front — a proper winch. 600W of peak power and 85Nm of torque — a strong full-power motor.
Strong up and composed down — a do-it-all, not a specialist.
Brilliant on fast, rough, steep terrain; less fun on tight, mellow trails.
How it stacks up vs other Full Power · Trail bikes (from 223 bikes in the database)
Weight24.9 kg1.9 kg heavier than average
Battery750 Whabout average capacity
Motor torque85 Nm13 Nm below average
Value for money40/100from £5,220 · most Bosch Performance Line CX Gen 4 bikes ~£4,899
⚙️ Adjustable geometry: this frame has a high/low setting — low drops the BB and slackens the head angle for more descending stability; high lifts the BB and steepens slightly for clearance and a perkier, more playful feel.
Computed from geometry + spec, not a paid review. Scores are guidance, not gospel.
Geometry · hover a row to highlight the measurement on the bike
| S | M | L | XL | |
|---|---|---|---|---|
| Reach | 450 mm | 470 mm | 490 mm | 510 mm |
| Stack | 622 mm | 622 mm | 640 mm | 640 mm |
| Seattube | 380 mm | 420 mm | 450 mm | 490 mm |
| Chainstay | 455 mm | 455 mm | 455 mm | 455 mm |
| Headtube Angle | 65.5° | 65.5° | 65.5° | 65.5° |
| Seattube Angle (eff) | 76° | 76° | 76° | 76° |
| Wheelbase | 1225 mm | 1245 mm | 1265 mm | 1285 mm |
| Headtube | 110 mm | 110 mm | 130 mm | 130 mm |
| BB Height | 350 mm | 350 mm | 350 mm | 350 mm |
| Front Centre | 770 mm* | 790 mm* | 810 mm* | 830 mm* |
| FC:RC | 1.69 | 1.74 | 1.78 | 1.82 |
Trims · 3
Chaser RX £5,220 | Chaser R | Chaser X | |
|---|---|---|---|
| Motor | Bosch Performance Line CX Gen 4 · 85 Nm · all trims | ||
| Battery | Bosch PowerTube 750 · 750 Wh · all trims | ||
| Travel F/R | 160/150 mm · all trims | ||
| Frame | Chaser 6061 Alloy Stealth Evo, e-Bike Optimized Zero Suspension System, 140mm travel, Forward Geometry, internal non-removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, exclusive plastic motor covers, shock mudguard | Chaser 6061 Alloy Stealth Evo, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers, shock mudguard | Chaser 6061 Alloy Stealth Evo, e-Bike Optimized Zero Suspension System, 140mm travel, Forward Geometry, internal removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, exclusive plastic motor covers, shock mudguard. Urban-equipped: front/rear lights, MDK alloy fenders, MDK alloy rear rack (25kg max), Massload KSA18-40 kickstand, urban resin pedals |
| Fork | RockShox 35 Silver TK 29, 150mm, TurnKey, Solo Air, tapered steerer tube, Boost 15x110mm axle, 35mm steel stanchions, 44mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload | Fox 36 29 Float FIT GRIP EVOL Rhythm, 160mm, e-bike tuned, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: sweep adjust compression, Low-speed rebound, air preload | RockShox Recon Silver RL 29, 150mm, Solo Air, tapered steerer tube, Boost 15x110mm axle, 35mm steel stanchions, 44mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload |
| Shock | RockShox Deluxe Select R DebonAir, 205x60mm. Settings: Low-speed rebound, air preload. Trunnion top mount, 25x10mm bottom bushings. Shock settings: Light compression, Linear rebound, 1 Token | Fox Float EVOL Performance, 205x65mm. Settings: 2-position compression adjustment (Open/Firm), rebound, air preload. Trunnion top mount, 25x10mm bottom bushings | RockShox Deluxe Select R DebonAir, 205x60mm. Settings: Low-speed rebound, air preload. Trunnion top mount, 25x10mm bottom bushings. Shock settings: Light compression, Linear rebound, 1 Token |
| Headset | Onoff Saturn tapered for 1-1/8in to 1-1/2in head tube, ACB sealed bearings, top 41x30.2x7x45 deg x45 deg, bottom 51.9x40x8x45 deg x45 deg · all trims | ||
| Stem | MDK Urban 35mm 0 deg, 6061 forged alloy, 31.8mm barbore | Onoff Sulfur FG 30mm 0 deg, 6061 forged alloy, 31.8mm barbore | MDK Urban 35mm 0 deg, 6061 forged alloy, 31.8mm barbore |
| Handlebar | Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9 deg backsweep, 5 deg upsweep, 31.8mm barbore · all trims | ||
| Grips | Onoff Twin, 1 lock-on, 135mm · all trims | ||
| Saddle | MDK urban | MDK ebike black | MDK urban |
| Seatpost | Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S: 405x95-125mm, M: 458x120-150mm, L: 498x140-170mm, XL: 558x170-200mm | Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S: 405x95-125mm, M: 458x120-150mm, L: 498x140-170mm, XL: 558x170-200mm | Onoff Sulfur 0-R, 6061 T6 Alloy, 3D forged, diameter 31.6mm, length 400mm (rigid, non-dropper) |
| Brakes | Sram DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor front and rear, steel-backed organic pads. Brake lever: Sram DB8, tool reach adjust, lever pivot bushings · all trims | ||
| Rear derailleur | Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1 | Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1 | Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1 |
| Crank | Race Face Aeffect ebike, 165mm. Rings: Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD · all trims | ||
| Shifters | Sram Trigger SX Eagle, 12s, X-Actuation 1:1, single click · all trims | ||
| Cassette | Sram PG-1210, 11-50T, 12s · all trims | ||
| Chain | Sram SX Eagle, 12s, Powerlock · all trims | ||
| Drivetrain | Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1; Race Face Aeffect ebike, 165mm. Rings: Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD; Sram Trigger SX Eagle, 12s, X-Actuation 1:1, single click; Sram PG-1210, 11-50T, 12s; Sram SX Eagle, 12s, Powerlock | Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1; Race Face Aeffect ebike, 165mm. Rings: Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD; Sram Trigger SX Eagle, 12s, X-Actuation 1:1, single click; Sram PG-1210, 11-50T, 12s; Sram SX Eagle, 12s, Powerlock | Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1; Race Face Aeffect ebike, 165mm. Rings: Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD; Sram Trigger SX Eagle, 12s, X-Actuation 1:1, single click; Sram PG-1210, 11-50T, 12s; Sram SX Eagle, 12s, Powerlock |
| Wheels | MDK-HP1 29, 30mm internal width, tubeless ready, 32 spokes. CN round stainless steel spokes. Formula DC711 front hub (Boost 15x110mm), Formula EHL148 rear hub (Boost 12x148mm), sealed bearings, IS 6 bolts, HG freehub | Mavic E-Deemax 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes. Mavic J-bend double butted spokes, contactless lacing. Mavic hubs, Boost 15x110mm front / 12x148mm rear, ID360 Ratchet system, IS 6 bolts, HG freehub | MDK-HP1 29, 30mm internal width, tubeless ready, 32 spokes. CN round stainless steel spokes. Formula DC711 front hub (Boost 15x110mm), Formula EHL148 rear hub (Boost 12x148mm), sealed bearings, IS 6 bolts, HG freehub |
| Tyres | Maxxis Ikon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead, front and rear | Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead, front and rear | Maxxis Ikon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead, front and rear |
| Weight | 26.5 kg | 24.9 kg | 26.5 kg |
| Price | £5,220 | — | — |
