Bike Finder · Megamo

Megamo Crave AL
Megamo

Crave AL 2022

DiscontinuedFull Power · TrailLegacy · 0.4/10iFreshness 0.4/10
How current the bike is — newer chassis, motor and battery score higher. 10 = brand-new, 0 = legacy.

Alloy all-mountain bike with dependable Shimano power for varied trails

Travel F/R
160/150mm
Wheels
29F / 29R
Frame
Aluminium
Weight
Price
From €4,289
View the Megamo Crave AL on Megamo’s site
Megamo Crave AL 2022
EMTB Forums verdict

The Megamo Crave AL 2022 is the aluminium-framed version of the Spanish brand's full-suspension trail and all-mountain eMTB, with the carbon Crave CRB as its sibling. The chassis uses a Horst Link 4-bar layout, a triple-butted alloy frame with a fully integrated battery and 29in wheels running roomy 2.6in Maxxis Minion rubber. Megamo quotes 150 mm of rear travel matched to a 160 mm fork on most trims. Geometry is shared across the whole range, with a 65.3-degree head angle, a 75-degree effective seat angle, 465 mm chainstays and reach growing from 431 mm on the S to 474 mm on the L.

Every 2022 build carries an integrated 630 Wh battery, but the motor changes as you move down the line. The Gravity, AL 03 and AL 05 use the Shimano EP8 (85 Nm), the AL 10 runs the newer Shimano EP801 (85 Nm), and the entry AL 40 steps down to the Shimano EP6 mid-power unit. The Gravity tops the range at 7,599 euros with a Fox 38 Factory fork, a coil Fox Float DHX2 shock, Shimano XT gearing and DT Swiss wheels. The AL 03 (6,499 euros) keeps the Fox 38 but swaps to an air Fox DPX2 shock, the AL 05 (5,399 euros) drops to a 150 mm Fox 34 Rhythm and Shimano Deore, the AL 10 (4,289 euros) moves to a RockShox 35 Silver fork and SRAM SX Eagle, and the AL 40 EP6 (4,449 euros) pairs a 130 mm Suntour XCR 34 fork with a 10-speed Shimano Deore drivetrain.

Megamo has limited UK retail presence, so pricing here is quoted in euros from the manufacturer's own 2022 catalogue rather than a British RRP. This is a discontinued 2022 model; later Crave AL generations moved to a larger 762 Wh battery and standardised on the Shimano EP801 motor. No independent owner ride or reliability data is included here.

Geometry read

What the numbers mean on the trail

Computed from this bike's geometry, spec and build kit — reach, wheelbase, chainstay, head and seat angles, travel, motor, weight and the fork/tyre/brake spec — and worked out per size, because a fixed chainstay can make an S and an XL feel very different.

Size
Descending
59

A solid all-round descender (65.3° head angle, 150mm) — capable in the rough and steep without being an all-out bruiser.

Playfulness
23

More planted than poppy — better on steep terrain than tight, fiddly singletrack.

Size balance
93

Rear-long with a planted front in L (FC:RC 1.75) — easy to weight the front and quick to turn, though it can feel light at the back at real speed.

Technical climbing
74

Shimano EP8 (DU-EP800) and a steep 75° seat angle keep the weight planted over the front — a proper winch. 500W of peak power and 85Nm of torque — a strong full-power motor.

Best suited toBig-day all-rounders who climb a lot and still descend hard.

Strong up and composed down — a do-it-all, not a specialist.

Watch out forNot a flickable, playful bike — built to plough, not pop.

Brilliant on fast, rough, steep terrain; less fun on tight, mellow trails.

How it stacks up vs other Full Power · Trail bikes (from 271 bikes in the database)

Battery630 Wh74 Wh below average
Motor torque85 Nm13 Nm below average
Computed from geometry + spec, not a paid review. Scores are guidance, not gospel.
Paste into any thread to embed this live, interactive panel.

Geometry · hover a row to highlight the measurement on the bike

Bike geometry diagram
SML
Reach431 mm450 mm474 mm
Stack630 mm634 mm639 mm
Seattube406 mm457 mm508 mm
Chainstay465 mm465 mm465 mm
Headtube Angle65.3°65.3°65.3°
Seattube Angle (eff)75°75°75°
Wheelbase1232 mm1253 mm1279 mm
Headtube135 mm140 mm145 mm
BB Height370 mm370 mm370 mm
Front Centre767 mm*788 mm*814 mm*
FC:RC1.651.691.75

Trims · 5

03
€6,499
05
€5,399
10
€4,289
40
€4,449
Gravity
€7,599
MotorShimano EP8 (DU-EP800) · 85 NmShimano EP8 (DU-EP800) · 85 NmShimano EP801 · 85 NmShimano EP6 (DU-EP600) · 85 NmShimano EP8 (DU-EP800) · 85 Nm
BatteryIntegrated 630Wh · 630 Wh · all trims
Travel F/R160/150 mm · all trims
FrameAluminium (Triple Butted alloy, fully integrated battery) · all trims
ForkFox 38 Factory e-bike+, Kashima 29, 160mm, grip 2, 15QRx110, 44mm rakeFOX 34 Rhythm e-Bike, Float 29, 150mm, grip, sweep-adj, 15QRx110 Boost, 44mm rakeRock Shox 35 Silver R 29" Boost 15x110mm 160mm E-MTB Tapered SteererSuntour XCR 34 E-Bike+, Travel 130mm, Boost 15x110, Mini-Fender IncludedFox 38 Factory e-bike+, Kashima 29, 160mm, grip 2, 15QRx110, 44mm rake
ShockFox Float DPX2, Factory Series, Kashima 3pos-adj, Trunnion, Evol LV, 205x65FOX Float DPS, Performance Series, 3pos, Trunnion, Evol LV, 205x65Rock Shox Deluxe Select R 205x65 Debonair Tune TrunnionRock Shox Deluxe Select R 205x65 Debonair Tune TrunnionFOX Float DHX2, Factory Series, Kashima 3pos-Adj, Trunnion
HeadsetFSA Orbit 1,5 E ZS 1-1/8" 1,5" · all trims
Stem3D Forged Alloy, Ext.: 60-70-90 mm, Rise: +/-7deg · all trims
HandlebarAlloy Butted 31,8x780 mm, Rise: 12 mm, Back Sweep: 6degAlloy Butted 31,8x780 mm, Rise: 12 mm, Back Sweep: 6degAlloy Butted 31,8x780 mm, Rise: 12 mm, Back Sweep: 6degAlloy Butted 31,8x780 mm, Rise: 12 mm, Back Sweep: 6deg
SaddleMegamo Specific E-Bike+ SaddleSellie Italia Model X SuperflowSellie Italia Model X SuperflowSellie Italia Model X SuperflowMegamo Specific E-Bike+ Saddle
SeatpostFOX Transfer, Factory series (Kashima), 30.9mm, Internal Routing, RemoteMegamo 30,9mm Dropper post, remote adjustmentMegamo 30,9mm Dropper post, remote adjustmentMegamo 30,9mm telescopic seat post, remote adjustmentFOX Transfer, Factory series (Kashima), 30.9mm, Internal Routing, Remote
BrakesShimano MT520 hydraulic disc 4-Piston, 203mmShimano MT520 hydraulic disc 4-Piston, 203mmShimano MT420 hydraulic disc 4-Piston, 203mmShimano MT420 hydraulic disc 4-Piston, 203mmShimano MT520 hydraulic disc 4-Piston, 203mm
Rear derailleurShimano XT 12sShimano Deore 12sSram SX Eagle 12sShimano Deore 6000 10sShimano XT 12s
CrankShimano 36tShimano 36tSram Chainring 36TShimano 34TShimano 36t
ShiftersShimano Deore 12sShimano Deore 12sSram SX Eagle 12sShimano Deore 10sShimano Deore 12s
CassetteShimano deore 12s 10-51tShimano Deore 12s 10-51tSram SX Eagle 12s 11-50tShimano Deore 11-42T 10sShimano deore 12s 10-51t
DrivetrainShimano XT 12s; Shimano 36t; Shimano Deore 12s; Shimano deore 12s 10-51tShimano Deore 12s; Shimano 36t; Shimano Deore 12s; Shimano Deore 12s 10-51tSram SX Eagle 12s; Sram Chainring 36T; Sram SX Eagle 12s; Sram SX Eagle 12s 11-50tShimano Deore 6000 10s; Shimano 34T; Shimano Deore 10s; Shimano Deore 11-42T 10sShimano XT 12s; Shimano 36t; Shimano Deore 12s; Shimano deore 12s 10-51t
Wheels29 Asymmetric 15x110 12x148 Boost Wide:30mm Tubeless Ready29 Asymmetric 15x110 12x148 Boost Wide:30mm Tubeless Ready29 Asymmetric 15x110 12x148 Boost Wide:30mm Tubeless Ready29 Asymmetric 15x110 12x148 Boost Wide:30mm Tubeless ReadyDT Swiss 1501 HX 30 - MSPLINE
TyresFront: 29x2,6 Maxxis Minion DHF, Rear: 29x2,6 Maxxis Minion DHR II, Tubeless Ready, EXO ProtectionFront: 29x2,6 Maxxis Minion DHF, Rear: 29x2,6 Maxxis Minion DHR II, Tubeless Ready, EXO Protection / Pirelli Scorpion Eduro S HardWALLFront: 29x2,6 Maxxis Minion DHF, Rear: 29x2,6 Maxxis Minion DHR II, Tubeless Ready, EXO ProtectionMaxxis Rekon 29 x 2,60 EXO FoldableFront: 29x2,6 Maxxis Minion DHF, Rear: 29x2,6 Maxxis Minion DHR II, Tubeless Ready, EXO Protection
Price€6,499€5,399€4,289€4,449€7,599
