Overvolt HT 2026
How current the bike is — newer chassis, motor and battery score higher. 10 = brand-new, 0 = legacy.
The Lapierre Overvolt HT is the brand's entry-level hardtail eMTB, built around a Supreme 5 aluminium frame and a Bosch Performance Line CX motor (85 Nm) drawing on the gravity of an integrated PowerTube downtube pack: 800Wh on the flagship 8.8 High, 600Wh on the 6.6 High. There is no rear shock and no rear travel; all 120mm of squish sits up front.
The frame uses a size-split wheel layout, with the smaller S and M frames on 27.5in wheels (steeper 68 degree head angle, 465mm stays) and the larger L and XL on 29in (67 degree head angle, 475mm stays). The 74 degree seat angle and roomy 422 to 472mm reach span keep the fit sensible for trail duty rather than pure cross country.
Build kit is honest commuter-to-trail fare: Shimano CUES U6000 10 or 11 speed, MT401 two piston hydraulic brakes on 203mm rotors front and rear, and Ryde Disc30 rims. The 8.8 High earns Maxxis Minion DHF and Rekon rubber plus a Limotec dropper, where the 6.6 High runs Schwalbe Nobby Nic tyres and a rigid alloy post. At 23.7kg it is no featherweight, but the 800Wh battery and CX motor make it a capable first electric hardtail for mixed trails.
Geometry · hover a row to highlight the measurement on the bike
| S | M | L | XL | |
|---|---|---|---|---|
| Reach | 422 mm | 432 mm | 452 mm | 472 mm |
| Stack | 656 mm | 674 mm | 683 mm | 692 mm |
| Seattube | 400 mm | 450 mm | 500 mm | 550 mm |
| Chainstay | 465 mm | 465 mm | 475 mm | 475 mm |
| Headtube Angle | 68° | 68° | 67° | 67° |
| Seattube Angle (eff) | 74° | 74° | 74° | 74° |
| Wheelbase | 1171 mm | 1216 mm | 1240 mm | 1264 mm |
| Headtube | 140 mm | 150 mm | 160 mm | 160 mm |
| Front Centre | 706 mm* | 751 mm* | 765 mm* | 789 mm* |
Trims · 2
6.6 High £3,099 | 8.8 High £3,699 | |
|---|---|---|
| Motor | Bosch Performance Line CX Gen 4 · 85 Nm · all trims | |
| Battery | Bosch PowerTube 800 · 800 Wh · all trims | |
| Travel F/R | 120/? mm · all trims | |
| Frame | Aluminium - Supreme 5 alloy · all trims | |
| Fork | Suntour, XCR34 Coil 15x110 29" 120 mm | Rockshox, Psylo Silver R 15x110 29" 120 mm |
| Headset | Feimin, Semi-integrated, FPH856U 1.1/8" - 1.5 Tapered · all trims | |
| Stem | Lapierre, Alloy forged, 0 deg, O: 31.8 mm, L: 40 mm (also 50 mm) · all trims | |
| Handlebar | Lapierre, Flat bar, Alloy 6061 DB, Rise: 15 mm, O: 31.8 mm, 760 mm · all trims | |
| Grips | Lapierre, grips small diameter · all trims | |
| Saddle | Selle Royal, Vivo · all trims | |
| Seatpost | Lapierre, Non Suspension, Alloy, O: 34.9 mm, L: 300 mm (rigid, no dropper) | Limotec, Dropperpost, Alpha A1 34.9 mm, travel: 100 mm (also 125 mm) |
| Brakes | Shimano, hydraulic disc brake, MT401 2 piston (front and rear), 203 mm; rotors Shimano, SM-RT30 203 mm, Centerlock · all trims | |
| Rear derailleur | Shimano, CUES U6000 10/11s Shadow+ · all trims | |
| Crank | XLC, Crank + chainring, 34T single · all trims | |
| Shifters | Shimano, Triggershift, CUES U6000 10s (right: SL-U6000-10R) | Shimano, Triggershift, CUES U6000 11s (right: SL-U6000-11R) |
| Cassette | Shimano, CUES CS-LG300-10, HG, 11-48T | Shimano, CUES CS-LG400-11, HG, 11-50T |
| Chain | Shimano, CUES LG500 9/10/11s · all trims | |
| Drivetrain | Shimano, CUES U6000 10/11s Shadow+; XLC, Crank + chainring, 34T single; Shimano, Triggershift, CUES U6000 10s (right: SL-U6000-10R); Shimano, CUES CS-LG300-10, HG, 11-48T; Shimano, CUES LG500 9/10/11s | Shimano, CUES U6000 10/11s Shadow+; XLC, Crank + chainring, 34T single; Shimano, Triggershift, CUES U6000 11s (right: SL-U6000-11R); Shimano, CUES CS-LG400-11, HG, 11-50T; Shimano, CUES LG500 9/10/11s |
| Wheels | Ryde, Disc30 32H, 30-584 Black Anodized (front and rear) · all trims | |
| Tyres | Schwalbe Nobby Nic Performance 65-584 (front and rear) | Front: Maxxis Minion DHF EXO TR 29x2.6(S)/29x2.50 WT(M,L,XL); Rear: Maxxis Rekon EXO TR 29x2.6(S)/29x2.40(M,L,XL) |
| Weight | — | 23.7 kg |
| Price | £3,099 | £3,699 |
