KTM

Macina Kapoho 2023

Discontinued✎Full Power · EnduroLegacy · 1/10iFreshness 1/10
How current the bike is — newer chassis, motor and battery score higher. 10 = brand-new, 0 = legacy.

Motor

Bosch Performance Line CX Gen 4 · 85Nm · 600W↗

Battery

Bosch PowerTube 750 · 750Wh

Travel F/R

160/160mm

Wheels

MX (29F / 27.5R)✎

Frame

Aluminium / Full carbon

Weight

25.2 kg

Price

—

View the KTM Macina Kapoho on KTM’s site

KTM Macina Kapoho 2023

The 2023 KTM Macina Kapoho was the Austrian brand's 160mm enduro eMTB, built on the in-house STRAIGHT-LINE-LINK suspension and powered throughout by the Bosch Performance Line CX Gen 4 (85Nm) with the Smart System and a 750Wh PowerTube. Every trim ran KTM's DiMMiX mullet wheel concept, a 29in front paired with a 27.5in PLUS rear, for stability up front and traction at the back.Six builds spanned two frames. The carbon Prestige, Master and Elite sat near 25kg, topped by the Prestige with a Fox 36 Factory fork, Float X Factory shock and a Shimano XTR groupset. The aluminium 7971, 7972 and 7973 came in heavier at 27.5 to 27.8kg, ranging from a wireless SRAM GX Eagle AXS build on the 7971 down to a SRAM SX Eagle and Suntour-shocked 7973.Geometry was middle-of-the-road for the era: a 65.3-degree head angle on the carbon frames (66 degrees on alloy), a 76.5-degree effective seat angle and 442mm chainstays across all three sizes (M, L, XL). Reach ran 445 to 480mm on carbon.The Macina Kapoho has since been discontinued and replaced in KTM's range, so it is now found only on the used market and through remaining old-stock dealers.

EMTB Forums verdict

The 2023 KTM Macina Kapoho was the Austrian brand's 160mm enduro eMTB, built on the in-house STRAIGHT-LINE-LINK suspension and powered throughout by the Bosch Performance Line CX Gen 4 (85Nm) with the Smart System and a 750Wh PowerTube. Every trim ran KTM's DiMMiX mullet wheel concept, a 29in front paired with a 27.5in PLUS rear, for stability up front and traction at the back.

Six builds spanned two frames. The carbon Prestige, Master and Elite sat near 25kg, topped by the Prestige with a Fox 36 Factory fork, Float X Factory shock and a Shimano XTR groupset. The aluminium 7971, 7972 and 7973 came in heavier at 27.5 to 27.8kg, ranging from a wireless SRAM GX Eagle AXS build on the 7971 down to a SRAM SX Eagle and Suntour-shocked 7973.

Geometry was middle-of-the-road for the era: a 65.3-degree head angle on the carbon frames (66 degrees on alloy), a 76.5-degree effective seat angle and 442mm chainstays across all three sizes (M, L, XL). Reach ran 445 to 480mm on carbon.

The Macina Kapoho has since been discontinued and replaced in KTM's range, so it is now found only on the used market and through remaining old-stock dealers.

Geometry read

What the numbers mean on the trail

Computed from this bike's geometry, spec and build kit — reach, wheelbase, chainstay, head and seat angles, travel, motor, weight and the fork/tyre/brake spec — and worked out per size, because a fixed chainstay can make an S and an XL feel very different.

Size

Setting

Descending

A solid all-round descender (66° head angle, 160mm) — capable in the rough and steep without being an all-out bruiser.

Playfulness

A fair bit of pop, but happiest on flowing trail rather than trials moves.

Size balance

Rear-long with a planted front in L (FC:RC 1.78) — easy to weight the front and quick to turn, though it can feel light at the back at real speed.

Technical climbing

Bosch Performance Line CX Gen 4 and a steep 76.5° seat angle keep the weight planted over the front — a proper winch. 600W of peak power and 85Nm of torque — a strong full-power motor.

Best suited toAll-round trail riding across mixed terrain.

No single standout trait — a balanced, versatile bike.

Watch out forNo major red flags in the L geometry.

The numbers are well balanced for its category.

How it stacks up vs other Full Power · Enduro bikes (from 137 bikes in the database)

Weight25.2 kg1.4 kg heavier than average

Battery750 Whabout average capacity

Motor torque85 Nm18 Nm below average

Computed from geometry + spec, not a paid review. Scores are guidance, not gospel.

Paste into any thread to embed this live, interactive panel.

Geometry · hover a row to highlight the measurement on the bike

Flip-chip position

geometry changes with the chip

	M	L	XL
Reach	443 mm	462 mm	481 mm
Stack	607 mm	616 mm	630 mm
Seattube	430 mm	450 mm	480 mm
Chainstay	442 mm	442 mm	442 mm
Headtube Angle	66°	66°	66°
Seattube Angle (eff)	76.4°	76.5°	76.6°
Wheelbase	1206 mm	1228 mm	1251 mm
Headtube	100 mm	110 mm	125 mm
BB Height	—	—	—
Standover	803 mm	805 mm	807 mm
Front Centre	764 mm*	786 mm*	809 mm*
FC:RC	1.73	1.78	1.83

Trims · 6

	7971	7972	7973	Elite	Master	Prestige
Motor	Bosch Performance Line CX Gen 4 · 85 Nm · all trims
Battery	Bosch PowerTube 750 · 750 Wh · all trims
Travel F/R	160/160 mm · all trims
Frame	Aluminium	Aluminium	Aluminium	Carbon	Carbon	Carbon
Fork	FOX 36 Float 29" Rhythm e-bike 160mm 15x110	FOX 36 Float 29" Rhythm e-bike 160mm 15x110	RockShox 35 Silver TK 29" 160mm 15x110 taper	RockShox 35 Silver TK 29" 160mm 15x110 taper	FOX 36 Float 29" Performance e-bike 160mm 15x110	FOX 36 Float 29" Factory e-bike 160mm FIT4 15x110
Shock	FOX Float X Performance 2-Pos 250x70	FOX Float X Performance 2-Pos 250x70	Suntour Tri-Air 3CR 3-Pos 250x70	FOX Float X Performance 2-Pos 250x70	FOX Float X Performance 2-Pos 250x70	FOX Float X Factory 2-Pos 250x70
Headset	Acros AICR internal 1.1/8"-1.5" angle limit · all trims
Stem	KTM TEAM II Trail35 · all trims
Handlebar	KTM Team Trail35 rizer25 800mm	KTM Team Trail35 rizer25 800mm	KTM COMP II Trail35 rizer15 780mm	KTM Team Trail35 rizer25 800mm	KTM Team Trail35 rizer25 800mm	KTM Prime Trail35 Carbon rizer20 800mm
Grips	Ergon GA20 · all trims
Saddle	Selle San Marco Ground Short Open Fit Narrow	Selle San Marco RND Manganese Rails	Selle Italia Model-X Flow	Selle San Marco Ground Short Open Fit Narrow	Selle San Marco Ground Short Open Fit Narrow	Selle San Marco GND Open Fit Supercomfort Manganese Rails
Seatpost	KTM COMP II dropper internal	KTM COMP II dropper internal	KTM COMP II dropper internal	KTM COMP II dropper internal	KTM COMP II dropper internal	FOX Transfer Factory internal
Brakes	SRAM DB8 4-Piston	Tektro HD-M750 / E730 4-Piston	Shimano M4100 / MT420 4-Piston	Shimano M4100 / MT420 4-Piston	Shimano Deore XT M8100 / M8120 4-Piston	Shimano XTR M9100 / M9120 4-Piston
Rear derailleur	SRAM GX Eagle AXS 12speed	Shimano Deore XT M8100-12 SGS shadow+	SRAM SX Eagle 12speed	Shimano Deore XT M8100-12 SGS shadow+	Shimano Deore XT M8100-12 SGS shadow+	Shimano XTR M9100-12 SGS shadow+
Crank	KTM E-TRAIL ISIS 160mm Q16; SRAM X-Sync 2 Eagle 36T Direct Mount	KTM E-TRAIL ISIS 160mm Q16; FSA Megatooth steel 36T 12speed Direct Mount	KTM E-TRAIL ISIS 160mm Q16; SRAM X-Sync 2 Eagle 36T Direct Mount	KTM E-TRAIL ISIS 160mm Q16; FSA Megatooth steel 36T 12speed Direct Mount	KTM E-TRAIL ISIS 160mm Q16; FSA Megatooth steel 36T 12speed Direct Mount	KTM E-TRAIL ISIS 160mm Q16; FSA Megatooth steel 36T 12speed Direct Mount
Shifters	SRAM GX Eagle AXS Controller	Shimano Deore M6100-12	SRAM SX Eagle singleClick	Shimano Deore M6100-12	Shimano Deore XT M8100-12	Shimano XTR M9100-12
Cassette	SRAM NX Eagle PG-1230 / 11-50	Shimano Deore M6100-12 / 10-51	SRAM SX Eagle PG-1210 / 11-50	Shimano Deore M6100-12 / 10-51	Shimano Deore M6100-12 / 10-51	Shimano Deore XT M8100-12 / 10-51
Chain	SRAM NX Eagle 12s	Shimano M6100-12	SRAM NX Eagle 12s	Shimano M6100-12	Shimano M6100-12	Shimano M8100-12
Drivetrain	SRAM GX Eagle AXS 12speed; KTM E-TRAIL ISIS 160mm Q16; SRAM X-Sync 2 Eagle 36T Direct Mount; SRAM GX Eagle AXS Controller; SRAM NX Eagle PG-1230 / 11-50; SRAM NX Eagle 12s	Shimano Deore XT M8100-12 SGS shadow+; KTM E-TRAIL ISIS 160mm Q16; FSA Megatooth steel 36T 12speed Direct Mount; Shimano Deore M6100-12; Shimano Deore M6100-12 / 10-51; Shimano M6100-12	SRAM SX Eagle 12speed; KTM E-TRAIL ISIS 160mm Q16; SRAM X-Sync 2 Eagle 36T Direct Mount; SRAM SX Eagle singleClick; SRAM SX Eagle PG-1210 / 11-50; SRAM NX Eagle 12s	Shimano Deore XT M8100-12 SGS shadow+; KTM E-TRAIL ISIS 160mm Q16; FSA Megatooth steel 36T 12speed Direct Mount; Shimano Deore M6100-12; Shimano Deore M6100-12 / 10-51; Shimano M6100-12	Shimano Deore XT M8100-12 SGS shadow+; KTM E-TRAIL ISIS 160mm Q16; FSA Megatooth steel 36T 12speed Direct Mount; Shimano Deore XT M8100-12; Shimano Deore M6100-12 / 10-51; Shimano M6100-12	Shimano XTR M9100-12 SGS shadow+; KTM E-TRAIL ISIS 160mm Q16; FSA Megatooth steel 36T 12speed Direct Mount; Shimano XTR M9100-12; Shimano Deore XT M8100-12 / 10-51; Shimano M8100-12
Wheels	WHEEL F: KTM Line - Shimano MT410B CL 32H 110-15TA / Ambrosio E30 Trail 32H 622x30TC / DT Champion 2.0 black; WHEEL R: KTM Line - Shimano MT400B CL 32H 148-12TA / Ambrosio E35 Trail 32H 584x35TC / DT Alpine II 2.34 black	WHEEL F: KTM Line - Shimano MT410B CL 32H 110-15TA / Ambrosio E30 Trail 32H 622x30TC / DT Champion 2.0 black; WHEEL R: KTM Line - Shimano MT410B CL 32H 148-12TA / Ambrosio E35 Trail 32H 584x35TC / DT Alpine II 2.34 black	WHEEL F: KTM Line - Shimano MT410B CL 32H 110-15TA / Ambrosio E30 Trail 32H 622x30TC / DT Champion 2.0 black; WHEEL R: KTM Line - Shimano MT400B CL 32H 148-12TA / Ambrosio E35 Trail 32H 584x35TC / DT Alpine II 2.34 black	WHEEL F: KTM Line - Shimano MT410B CL 32H 110-15TA / Ambrosio E30 Trail 32H 622x30TC / DT Champion 2.0 black; WHEEL R: KTM Line - Shimano MT410B CL 32H 148-12TA / Ambrosio E35 Trail 32H 584x35TC / DT Alpine II 2.34 black	WHEEL F: KTM Line - DT Swiss 370 CL 28L 110/15 / Ambrosio E30 Trail 28H 622x30TC / DT Champion 2.0 black; WHEEL R: KTM Line - DT Swiss 370 CL 28L 148/12 12SP LN18 / Ambrosio E35 Trail 28H 584x35TC / DT Alpine II 2.34 black	WHEEL F: Mavic E-Deemax S 29 CL 110/15TA / 622x30TC; WHEEL R: Mavic E-Deemax S 27 CL 148/12TA / 584x35TC
Tyres	Front: Maxxis Minion DHF 3C-MaxxTerra/EXO/TR 63-622; Rear: Maxxis Minion DHR II 3C-MaxxTerra/EXO/TR 70-584	Front: Maxxis Minion DHF 3C-MaxxTerra/EXO/TR 63-622; Rear: Maxxis Minion DHR II 3C-MaxxTerra/EXO/TR 70-584	Front: Schwalbe Nobby Nic Perf. Folding 65-622; Rear: Schwalbe Nobby Nic Perf. Folding 70-584	Front: Maxxis Minion DHF 3C-MaxxTerra/EXO/TR 63-622; Rear: Maxxis Minion DHR II 3C-MaxxTerra/EXO/TR 70-584	Front: Maxxis Minion DHF 3C-MaxxTerra/EXO/TR 63-622; Rear: Maxxis Minion DHR II 3C-MaxxTerra/EXO/TR 70-584	Front: Schwalbe Eddy Current Front Evo SuperTrail TLE 65-622; Rear: Schwalbe Eddy Current Rear Evo SuperGravity TLE 70-584
Weight	27.5 kg	27.8 kg	27.6 kg	25.9 kg	25.3 kg	25.2 kg
