Descending
52
A solid all-round descender (66° head angle, 120mm) — capable in the rough and steep without being an all-out bruiser.
Haibike
AllTrack 2022
Discontinued✎Full Power · Cross-CountryLegacy · 1/10iFreshness 1/10
How current the bike is — newer chassis, motor and battery score higher. 10 = brand-new, 0 = legacy.
How current the bike is — newer chassis, motor and battery score higher. 10 = brand-new, 0 = legacy.
Full-power hardtail with big-battery range for long trail days
Motor
Bosch Performance Line CX Gen 4 · 85Nm · 600W↗
Battery
Bosch PowerTube 750 · 750Wh
Travel F/R
120mm / —
Wheels
29F / 29R✎
Frame
Aluminium✎
Weight
—
Price
£3,800
From £3,799
EMTB Forums verdict
The 2022 Haibike AllTrack 9 is an aluminium hardtail eMTB built around the Bosch Performance CX Gen 4 (Smart System) motor and a 750Wh integrated PowerTube battery, with an optional range extender taking total capacity to around 1125Wh. It is a trail-oriented hardtail rather than an enduro or trekking machine, running a 120 mm RockShox 35 Silver fork and mixed wheel sizing of 27.5in on size S and 29in on M, L and XL.
The build pairs a SRAM SX Eagle shifter and GX Eagle rear derailleur over an 11-50T 12-speed cassette, with Tektro Orion M745 four-piston hydraulic brakes on a 203 mm front rotor and Schwalbe Nobby Nic Performance 2.6in tyres. The cockpit is Haibike's own kit: an 780 mm TheBar ++ handlebar, TheStem ++ and an aluminium TheSeatpost ++, topped with an XLC MTB saddle.
Geometry is moderate by 2022 standards, with a 66 degree head angle and 73 degree seat angle across the 29in sizes, reach growing from 427 mm on the M to 462 mm on the XL, and chainstays of 470 mm. Stepping up the range, the AllTrack 10 swaps in a RockShox 35 Gold RL fork and the flagship AllTrack 11 adds a dropper post and an integrated ABS option, all sharing the same Bosch CX Gen 4 platform.
This bike is discontinued, so availability is limited to remaining stock and the used market. Launch UK pricing was around £3,799.99 for the AllTrack 9, with the 10 and 11 sitting above it.
Geometry read
What the numbers mean on the trail
Computed from this bike's geometry, spec and build kit — reach, wheelbase, chainstay, head and seat angles, travel, motor, weight and the fork/tyre/brake spec — and worked out per size, because a fixed chainstay can make an S and an XL feel very different.
Size
Wheels
Playfulness
45
A fair bit of pop, but happiest on flowing trail rather than trials moves.
Size balance
61
Rear-long with a planted front in L (FC:RC 1.61) — easy to weight the front and quick to turn, though it can feel light at the back at real speed.
Technical climbing
72
Bosch Performance Line CX Gen 4 and a steep 73° seat angle keep the weight planted over the front — a proper winch. 600W of peak power and 85Nm of torque — a strong full-power motor.
No single standout trait — a balanced, versatile bike.
The numbers are well balanced for its category.
How it stacks up vs other Full Power · Cross-Country bikes (from 130 bikes in the database)
Battery750 Wh63 Wh above average
Motor torque85 Nmabout average torque
Value for money37/100from £3,800 · most Bosch Performance Line CX Gen 4 bikes ~£3,499
Computed from geometry + spec, not a paid review. Scores are guidance, not gospel.
Geometry · hover a row to highlight the measurement on the bike
| S | M | L | XL | |
|---|---|---|---|---|
| Reach | 410 mm | 427 mm | 439 mm | 462 mm |
| Stack | 628 mm | 663 mm | 672 mm | 682 mm |
| Seattube | 410 mm | 440 mm | 480 mm | 520 mm |
| Chainstay | 460 mm | 470 mm | 470 mm | 470 mm |
| Headtube Angle | 65.5° | 66° | 66° | 66° |
| Seattube Angle (eff) | 73° | 73° | 73° | 73° |
| Wheelbase | 1182 mm | 1210 mm | 1226 mm | 1253 mm |
| Headtube | 140 mm | 140 mm | 150 mm | 160 mm |
| Front Centre | 722 mm* | 740 mm* | 756 mm* | 783 mm* |
| FC:RC | 1.57 | 1.57 | 1.61 | 1.67 |
Trims · 3
AllTrack 9 £3,800 | AllTrack 10 €4,699 | AllTrack 11 €4,999 | |
|---|---|---|---|
| Motor | Bosch Performance Line CX Gen 4 · 85 Nm · all trims | ||
| Battery | Bosch PowerTube 750 · 750 Wh · all trims | ||
| Travel F/R | 120/? mm · all trims | ||
| Frame | Aluminium · all trims | ||
| Fork | RockShox 35 Silver, 120 mm | RockShox 35 Gold RL, 120 mm | RockShox, 120 mm |
| Stem | Haibike Components TheStem ++, A-head, 31.8 mm, 7 degrees | — | — |
| Handlebar | Haibike Components TheBar ++, 780 mm | — | — |
| Grips | Haibike MTB grips | — | — |
| Saddle | XLC MTB | — | — |
| Seatpost | Haibike Components TheSeatpost ++, 34.9 mm, aluminium | — | Dropper Post |
| Brakes | Tektro Orion M745, 4-piston hydraulic disc | — | — |
| Rear derailleur | SRAM GX Eagle, 12-speed | — | — |
| Crank | 38T chainring | — | — |
| Shifters | SRAM SX Eagle, 12-speed | — | — |
| Cassette | SRAM PG1210, 12-speed, 11-50T | — | — |
| Drivetrain | SRAM GX Eagle, 12-speed; 38T chainring; SRAM SX Eagle, 12-speed; SRAM PG1210, 12-speed, 11-50T | — | — |
| Wheels | Aluminium, 29in | — | — |
| Tyres | Schwalbe Nobby Nic Performance, 29 x 2.6in | Schwalbe Nobby Nic | Schwalbe knobbly MTB tyres |
| Price | £3,800 | €4,699 | €4,999 |
