Haibike

AllMtn 2023

Discontinued✎Full Power · EnduroLegacy · 0.5/10iFreshness 0.5/10
How current the bike is — newer chassis, motor and battery score higher. 10 = brand-new, 0 = legacy.

Motor

Yamaha PW-X3 · 85Nm · 500W↗

Battery

Yamaha InTube 720 · 720Wh

Travel F/R

160/160mm

Wheels

MX (29F / 27.5R)✎

Frame

Aluminium✎

Weight

—

Price

From £3,949

View the Haibike AllMtn on Haibike’s site

Haibike AllMtn 2023

From £3,949

The 2023 Haibike AllMtn was the brand's alloy all-mountain workhorse: a mixed-wheel (29in front, 27.5in rear) full-suspension eMTB with 160mm of travel front and rear on a four-link frame. The headline drive across most of the range was Yamaha's PW-X3 (85Nm) with the 720Wh InTube battery, while the AllMtn 5 ran Bosch's Performance Line CX (Gen 4, Smart System) with a 750Wh PowerTube, and the entry-level AllMtn 1 used the gentler Yamaha PW-ST (70Nm) with a 630Wh pack. It has since been discontinued.The ladder is broad. The AllMtn 1 (3,949 pounds) is the value entry on a RockShox 35 Silver fork and the touring-tuned PW-ST motor. The AllMtn 2 (4,599 pounds) and 3 (4,799 pounds) step up to the PW-X3 with RockShox 35 Gold RL forks, TRP Slate or Shimano MT420 brakes and SRAM SX or Shimano Deore gearing. The AllMtn 4 (4,899 pounds) gains a RockShox Yari fork and Shimano SLX, and the AllMtn 5 (4,999 pounds) is the Bosch option with the same Yari fork and the larger 750Wh battery. The AllMtn 7 (5,599 pounds) is the standout mid-build with a FOX 36 Float Performance fork, Magura MT7 brakes and SRAM GX Eagle. The flagship AllMtn 10 (6,299 pounds) tops out with a FOX 38 Factory Kashima fork and Float X Factory shock, Shimano Deore XT and Mavic E-Deemax wheels.Geometry is consistent across the Yamaha alloy frame: a 64.5 degree head angle, a 75 degree seat tube angle and a 460mm chainstay on every size, with reach running 421mm (S) to 505mm (XL) and wheelbases from 1220mm to 1313mm. That is reasonably slack and moderately long for its era, leaning the AllMtn toward versatile trail and all-mountain duty rather than out-and-out enduro, with the 27.5in rear wheel and 460mm stays keeping it manageable on tight, technical trails.

EMTB Forums verdict

The 2023 Haibike AllMtn was the brand's alloy all-mountain workhorse: a mixed-wheel (29in front, 27.5in rear) full-suspension eMTB with 160mm of travel front and rear on a four-link frame. The headline drive across most of the range was Yamaha's PW-X3 (85Nm) with the 720Wh InTube battery, while the AllMtn 5 ran Bosch's Performance Line CX (Gen 4, Smart System) with a 750Wh PowerTube, and the entry-level AllMtn 1 used the gentler Yamaha PW-ST (70Nm) with a 630Wh pack. It has since been discontinued.

The ladder is broad. The AllMtn 1 (3,949 pounds) is the value entry on a RockShox 35 Silver fork and the touring-tuned PW-ST motor. The AllMtn 2 (4,599 pounds) and 3 (4,799 pounds) step up to the PW-X3 with RockShox 35 Gold RL forks, TRP Slate or Shimano MT420 brakes and SRAM SX or Shimano Deore gearing. The AllMtn 4 (4,899 pounds) gains a RockShox Yari fork and Shimano SLX, and the AllMtn 5 (4,999 pounds) is the Bosch option with the same Yari fork and the larger 750Wh battery. The AllMtn 7 (5,599 pounds) is the standout mid-build with a FOX 36 Float Performance fork, Magura MT7 brakes and SRAM GX Eagle. The flagship AllMtn 10 (6,299 pounds) tops out with a FOX 38 Factory Kashima fork and Float X Factory shock, Shimano Deore XT and Mavic E-Deemax wheels.

Geometry is consistent across the Yamaha alloy frame: a 64.5 degree head angle, a 75 degree seat tube angle and a 460mm chainstay on every size, with reach running 421mm (S) to 505mm (XL) and wheelbases from 1220mm to 1313mm. That is reasonably slack and moderately long for its era, leaning the AllMtn toward versatile trail and all-mountain duty rather than out-and-out enduro, with the 27.5in rear wheel and 460mm stays keeping it manageable on tight, technical trails.

Geometry read

What the numbers mean on the trail

Computed from this bike's geometry, spec and build kit — reach, wheelbase, chainstay, head and seat angles, travel, motor, weight and the fork/tyre/brake spec — and worked out per size, because a fixed chainstay can make an S and an XL feel very different.

Size

Descending

A solid all-round descender (64.5° head angle, 160mm) — capable in the rough and steep without being an all-out bruiser.

Playfulness

More planted than poppy — better on steep terrain than tight, fiddly singletrack.

Size balance

Rear-long with a planted front in L (FC:RC 1.78) — easy to weight the front and quick to turn, though it can feel light at the back at real speed.

Technical climbing

Climbs well — a 75° seat keeps the front planted. 500W of peak power and 85Nm of torque — a strong full-power motor.

Best suited toAll-round trail riding across mixed terrain.

No single standout trait — a balanced, versatile bike.

Watch out forNot a flickable, playful bike — built to plough, not pop.

Brilliant on fast, rough, steep terrain; less fun on tight, mellow trails.

How it stacks up vs other Full Power · Enduro bikes (from 132 bikes in the database)

Battery720 Whabout average capacity

Motor torque85 Nm18 Nm below average

Value for money59/100from £3,949 · most Yamaha PW-X3 bikes ~£4,199

Computed from geometry + spec, not a paid review. Scores are guidance, not gospel.

Paste into any thread to embed this live, interactive panel.

💬 Forum discussion

HAIBIKE SDURO ALLMTN 5.0 Owners

8 replies · 6.4k views · last reply 97 months ago

Join the discussion →

“Didn't have much time when I wrote this yesterday, so I'll elaborate a bit now. The old sduro allmtn frame geometry is a bit dated, and sort of the oposite of the modern long-low-slack trend. I'm 181/5'11 and had a Large. I only used…”

— knut7 · ♥ 3 · most-liked post

Geometry · hover a row to highlight the measurement on the bike

	S	M	L	XL
Reach	421 mm	451 mm	475 mm	505 mm
Stack	646 mm	646 mm	655 mm	664 mm
Chainstay	460 mm	460 mm	460 mm	460 mm
Headtube Angle	64.5°	64.5°	64.5°	64.5°
Seattube Angle (eff)	75°	75°	75°	75°
Wheelbase	1220 mm	1250 mm	1279 mm	1313 mm
Headtube	120 mm	120 mm	130 mm	140 mm
BB Height	354 mm	354 mm	354 mm	354 mm
Front Centre	760 mm*	790 mm*	819 mm*	853 mm*
FC:RC	1.65	1.72	1.78	1.85

Trims · 7

	1 £3,949	2 £4,599	3 £4,799	4 £4,899	5 £4,999	7 £5,599	10 £6,299
Motor	Yamaha PW-ST (70Nm) · 70 Nm	Yamaha PW-X3 · 85 Nm	Yamaha PW-X3 · 85 Nm	Yamaha PW-X3 · 85 Nm	Bosch Performance Line CX Gen 4 · 85 Nm	Yamaha PW-X3 · 85 Nm	Yamaha PW-X3 · 85 Nm
Battery	Yamaha InTube 720 · 720 Wh · all trims
Travel F/R	160/160 mm · all trims
Frame	Aluminium · all trims
Fork	RockShox 35 Silver, air, aluminium steerer tube 1 1/8" - 1 1/2" tapered, 15 x 110mm thru-axle Boost, 160mm	RockShox 35 Gold RL, air, 160mm travel, aluminium steerer tube 1 1/8" - 1 1/2" tapered, 15 x 110mm thru-axle Boost	RockShox 35 Gold RL, air, 160mm travel, aluminium steerer tube 1 1/8" - 1 1/2" tapered, 15 x 110mm thru-axle Boost	RockShox Yari RC, air, 160mm travel, aluminium steerer tube 1 1/8" - 1 1/2" tapered, 15 x 110mm thru-axle Boost	RockShox Yari RC, air, 160mm travel, aluminium steerer tube 1 1/8" - 1 1/2" tapered, 15 x 110mm thru-axle Boost	FOX 36 Float Performance, air, 160mm travel, lockout, aluminium steerer tube 1 1/8" - 1 1/2" tapered, 15 x 110mm thru-axle Boost	FOX 38 Factory Kashima, air, 160mm
Shock	SR Suntour Edge LO-R8, air, Trunnion Mount M8x25	RockShox Deluxe Select Plus, air, Trunnion Mount	RockShox Deluxe Select, air, Trunnion Mount	RockShox Deluxe Select Plus, air, Trunnion Mount	RockShox Deluxe Select Plus, air, Trunnion Mount	FOX Float DPS Performance EVOL LV Trunnion, air	FOX Float X Factory EVOL LV, air, Trunnion
Headset	Feimin A-Head Tapered	Acros BlockLock, aluminium	Acros BlockLock, aluminium	Acros BlockLock, aluminium	Feimin A-Head Tapered, aluminium, cartridge	Acros BlockLock, aluminium	Acros BlockLock, aluminium
Stem	Haibike TheStem++, 31.8mm, 7deg	Haibike Components TheStem +++, 31.8mm	Haibike Components TheStem ++, A-head, 31.8mm	Haibike Components TheStem +++, 31.8mm	Haibike Components TheStem ++, A-head, 31.8mm	Haibike Components TheStem +++, 31.8mm	Haibike Components TheStem +++, 31.8mm
Handlebar	Haibike TheBar+++ Gravity, 780mm	Haibike Components TheBar +++, 780mm	Haibike Components TheBar +++, 780mm	Haibike Components TheBar +++, 780mm	Haibike Components TheBar +++, 780mm	Haibike Components TheBar +++, 780mm	Haibike Components TheBar +++, 780mm
Grips	Haibike MTB grips · all trims
Saddle	Selle Royal Vivo 1216HRN	Selle Royal Vivo	Selle Royal Vivo	Selle Royal Vivo	Selle Royal Vivo	fi'zi:k Terra Aidon X5-160	fi'zi:k Terra Aidon X5-160
Seatpost	Haibike TheSeatpost++ rigid, 31.6mm	Haibike Components Dropper-Post Remote 34.9, aluminium, telescope, 34.9mm	Haibike Components Dropper-Post Remote 34.9, aluminium, telescope, 34.9mm	Haibike Components Dropper-Post Remote 34.9, aluminium, telescope, 34.9mm	Haibike Components Dropper-Post Remote 34.9, aluminium, telescope, 34.9mm	Haibike Components Dropper-Post Remote 34.9, aluminium, telescope, 34.9mm	Haibike Components Dropper-Post Remote 34.9, aluminium, telescope, 34.9mm
Brakes	Tektro Orion M745 4-piston, 203/180mm	TRP Slate T4, hydraulic disc, Tektro TR203 203mm rotors	Shimano MT420, 4-piston disc, 203mm	Shimano M6120, hydraulic disc, 203mm	Shimano MT420, 4-piston disc, 203mm	Magura MT7, 4-piston disc, Magura MDR-P 203mm rotors	Shimano Deore XT M8120, Shimano RT-MT800LE 203mm (F) / RT-EM810 203mm (R)
Rear derailleur	Shimano Deore M5100	SRAM SX Eagle	Shimano Deore M6100	Shimano SLX M7100	SRAM NX Eagle	SRAM GX Eagle	Shimano Deore XT M8100 Shadow Plus
Crank	Haibike Components, The Crank +, aluminium	Haibike Components, The Crank ++, aluminium	Haibike Components, The Crank ++, aluminium	Haibike Components, The Crank ++, aluminium	SRAM X/Sync II aluminium Eagle 36	Haibike Components, The Crank ++, aluminium	Haibike Components, The Crank ++, aluminium
Shifters	Shimano Deore M5100, 11-speed	SRAM SX Eagle, trigger switch	Shimano Deore M6100, trigger switch	Shimano Deore SLX M7100	SRAM SX Eagle	SRAM GX Eagle, trigger switch	Shimano Deore XT M8100, trigger switch
Cassette	Shimano M5100, 11-51T	SRAM Eagle PG1210, 11-50 teeth	Shimano M6100, 10-51 teeth	Shimano M6100, 10-51 teeth	SRAM Eagle PG1210, 11-50 teeth	SRAM Eagle PG1230, 11-50 teeth	Shimano M6100, 10-51 teeth
Chain	KMC X11e	SRAM SX Eagle	Shimano CN-M6100	Shimano CN-M6100	SRAM SX Eagle	SRAM SX Eagle	Shimano SLX M7100
Drivetrain	Shimano Deore M5100; Haibike Components, The Crank +, aluminium; Shimano Deore M5100, 11-speed; Shimano M5100, 11-51T; KMC X11e	SRAM SX Eagle; Haibike Components, The Crank ++, aluminium; SRAM SX Eagle, trigger switch; SRAM Eagle PG1210, 11-50 teeth; SRAM SX Eagle	Shimano Deore M6100; Haibike Components, The Crank ++, aluminium; Shimano Deore M6100, trigger switch; Shimano M6100, 10-51 teeth; Shimano CN-M6100	Shimano SLX M7100; Haibike Components, The Crank ++, aluminium; Shimano Deore SLX M7100; Shimano M6100, 10-51 teeth; Shimano CN-M6100	SRAM NX Eagle; SRAM X/Sync II aluminium Eagle 36; SRAM SX Eagle; SRAM Eagle PG1210, 11-50 teeth; SRAM SX Eagle	SRAM GX Eagle; Haibike Components, The Crank ++, aluminium; SRAM GX Eagle, trigger switch; SRAM Eagle PG1230, 11-50 teeth; SRAM SX Eagle	Shimano Deore XT M8100 Shadow Plus; Haibike Components, The Crank ++, aluminium; Shimano Deore XT M8100, trigger switch; Shimano M6100, 10-51 teeth; Shimano SLX M7100
Wheels	Rodi Tryp 30 (front) / Tryp 35 (rear)	WTB ST i30 TCS, double wall (front) / WTB ST i35 TCS, double wall (rear)	WTB ST i30 TCS, double wall (front) / WTB ST i35 TCS, double wall (rear)	WTB ST i30 TCS, double wall (front) / WTB ST i35 TCS, double wall (rear)	WTB ST i30 TCS, double wall (front) / WTB ST i35 TCS, double wall (rear)	Haibike TheHub++ hubs on WTB rims, Sapim Race spokes	Mavic E-Deemax
Tyres	Continental Trail King 29x2.4 (front) / 27.5x2.6 (rear)	Maxxis Minion DHF II 63-622 29x2.5 (F) / Minion DHR II 66-584 27.5x2.6 (R)	Maxxis Minion DHF II 63-622 29x2.5 (F) / Minion DHR II 66-584 27.5x2.6 (R)	Maxxis Minion DHF II 63-622 29x2.5 (F) / Minion DHR II 66-584 27.5x2.6 (R)	Maxxis Minion DHF II 63-622 29x2.5 (F) / Minion DHR II 66-584 27.5x2.6 (R)	Maxxis Minion DHF II 63-622 29x2.5 (F) / Minion DHR II 66-584 27.5x2.6 (R)	Maxxis Minion DHF II 63-622 29x2.5 (F) / Minion DHR II 66-584 27.5x2.6 (R)
Price	£3,949	£4,599	£4,799	£4,899	£4,999	£5,599	£6,299
