Devinci

E-Troy 2022

Discontinued✎Full Power · TrailLegacy · 0.4/10iFreshness 0.4/10
How current the bike is — newer chassis, motor and battery score higher. 10 = brand-new, 0 = legacy.

Sturdy alloy all-mountain bike on reliable Shimano EP8 power

Motor

Shimano EP8 (DU-EP800) · 85Nm · 500W↗

Battery

BMZ 725Wh

Travel F/R

160/150mm

Wheels

29F / 29R✎

Frame

Aluminium✎

Weight

24.7 kg

Price

From $7,599

View the Devinci E-Troy on Devinci’s site

Devinci E-Troy 2022

Launched on 25 May 2022, the all-new Devinci E-Troy is a 29in all-mountain eMTB built around 150mm of Split Pivot rear travel and a 160mm fork. The 6061-T6 aluminium frame (Optimum G04) carries Shimano's EP8 motor (85Nm) and a sizeable 725Wh BMZ battery, with moulded frame, motor and battery protection. It slots below the longer-travel E-Spartan (170mm rear / 180mm front) as Devinci's do-it-all electric trail bike.Geometry is modern but not extreme: a 64.8-degree head angle across all four sizes, steep 77.7 to 78.1-degree seat angles for climbing, a consistent 455mm chainstay and a 347mm BB height, with reach growing from 445mm (S) to 510mm (XL). Wheelbase spans 1227mm to 1305mm. There is no flip chip, so the geometry stays fixed.Two builds were offered, both on the alloy frame. The Deore 12S EP8 (US$7,599, 24.9kg) pairs a Fox 36 fork and Fox Float X with a full Shimano Deore drivetrain and MT520 four-piston brakes. The GX 12S (US$8,529, 24.7kg) steps up to a Fox 38 Performance Elite fork, SRAM GX Eagle, SRAM Code R brakes and RaceFace Aeffect wheels, making it the stronger pick for riders chasing the burlier chassis.

EMTB Forums verdict

Launched on 25 May 2022, the all-new Devinci E-Troy is a 29in all-mountain eMTB built around 150mm of Split Pivot rear travel and a 160mm fork. The 6061-T6 aluminium frame (Optimum G04) carries Shimano's EP8 motor (85Nm) and a sizeable 725Wh BMZ battery, with moulded frame, motor and battery protection. It slots below the longer-travel E-Spartan (170mm rear / 180mm front) as Devinci's do-it-all electric trail bike.

Geometry is modern but not extreme: a 64.8-degree head angle across all four sizes, steep 77.7 to 78.1-degree seat angles for climbing, a consistent 455mm chainstay and a 347mm BB height, with reach growing from 445mm (S) to 510mm (XL). Wheelbase spans 1227mm to 1305mm. There is no flip chip, so the geometry stays fixed.

Two builds were offered, both on the alloy frame. The Deore 12S EP8 (US$7,599, 24.9kg) pairs a Fox 36 fork and Fox Float X with a full Shimano Deore drivetrain and MT520 four-piston brakes. The GX 12S (US$8,529, 24.7kg) steps up to a Fox 38 Performance Elite fork, SRAM GX Eagle, SRAM Code R brakes and RaceFace Aeffect wheels, making it the stronger pick for riders chasing the burlier chassis.

Geometry read

What the numbers mean on the trail

Computed from this bike's geometry, spec and build kit — reach, wheelbase, chainstay, head and seat angles, travel, motor, weight and the fork/tyre/brake spec — and worked out per size, because a fixed chainstay can make an S and an XL feel very different.

Size

Descending

A solid all-round descender (64.8° head angle, 150mm) — capable in the rough and steep without being an all-out bruiser.

Playfulness

A fair bit of pop, but happiest on flowing trail rather than trials moves.

Size balance

Balanced front-to-rear in L (FC:RC 1.82) — weight sits evenly between the wheels.

Technical climbing

Shimano EP8 (DU-EP800) and a steep 77.9° seat angle keep the weight planted over the front — a proper winch. 500W of peak power and 85Nm of torque — a strong full-power motor.

Best suited toBig-day all-rounders who climb a lot and still descend hard.

Strong up and composed down — a do-it-all, not a specialist.

Watch out forNo major red flags in the L geometry.

The numbers are well balanced for its category.

How it stacks up vs other Full Power · Trail bikes (from 271 bikes in the database)

Weight24.7 kg1.7 kg heavier than average

Battery725 Whabout average capacity

Motor torque85 Nm13 Nm below average

Computed from geometry + spec, not a paid review. Scores are guidance, not gospel.

Paste into any thread to embed this live, interactive panel.

💬 Forum discussion

Devinci Troy e-lite

64 replies · 12.6k views · last reply 3 months ago

Join the discussion →

“I bought my E-Troy Lite about a month ago and already have over 200 km on it. I got the GX transmission build, and my first upgrade before trying the Magura was to swap them out with Hayes dominion A4, because I did not trust the stock…”

— fredmotokx · ♥ 5 · most-liked post

Geometry · hover a row to highlight the measurement on the bike

	S	M	L	XL
Reach	445 mm	465 mm	490 mm	510 mm
Stack	618 mm	627 mm	636 mm	645 mm
Seattube	400 mm	420 mm	445 mm	485 mm
Chainstay	455 mm	455 mm	455 mm	455 mm
Headtube Angle	64.8°	64.8°	64.8°	64.8°
Seattube Angle (eff)	78.1°	78°	77.9°	77.7°
Wheelbase	1227 mm	1252 mm	1281 mm	1305 mm
Headtube	95 mm	105 mm	115 mm	125 mm
BB Height	347 mm	347 mm	347 mm	347 mm
Standover	727 mm	739 mm	757 mm	778 mm
Front Centre	772 mm*	797 mm*	826 mm*	850 mm*
FC:RC	1.70	1.75	1.82	1.87

Trims · 2

	Deore 12S EP8 $7,599	GX 12S $8,529
Motor	Shimano EP8 (DU-EP800) · 85 Nm · all trims
Battery	BMZ 725Wh · 725 Wh · all trims
Travel F/R	160/150 mm · all trims
Frame	Aluminium (6061-T6, Optimum G04) · all trims
Fork	Fox 36 Performance E-Bike Grip 160 \| 51 Offset	Fox 38 Performance Elite E-Bike Grip2 160 \| 51 Offset
Shock	Fox Float X Performance Series Evol LV \| 0.6V Spacer \| 230x57.5	Fox Float X Performance Elite Evol LV \| 0.6V Spacer \| 230x57.5
Headset	FSA SX Pro \| 1.5 · all trims
Stem	V2 Pro \| B:35mm \| L:40mm \| 0deg · all trims
Handlebar	V2 Pro \| B:35mm \| R:25mm \| W:780mm · all trims
Grips	Devinci Performance \| w/lock-on · all trims
Saddle	SDG BELAIR Max eMTB · all trims
Seatpost	TranzX \| 34.9mm \| 1x Lever	SDG Tellis \| 34.9mm
Brakes	Shimano MT520/MT501 \| 4 Pistons	SRAM Code R \| 4 Pistons
Rear derailleur	Shimano Deore M6100 \| 12s	SRAM GX Eagle \| 12s
Crank	Shimano STEPS EM600 \| Shimano SM-CRE80 34T	E13 ESpec Plus 165mm \| SRAM X-Sync Eagle 34T EMTB
Shifters	Shimano Deore M6100 \| 12s	SRAM GX Eagle 12s Single Click
Cassette	Shimano M6100 \| 12s \| 10-51T \| Microspline	SRAM PG1230 \| 12s \| 11-50T \| HG
Chain	Shimano Deore M6100 \| 12s	SRAM GX Eagle \| 12s
Drivetrain	Shimano Deore M6100 \| 12s; Shimano STEPS EM600 \| Shimano SM-CRE80 34T; Shimano Deore M6100 \| 12s; Shimano M6100 \| 12s \| 10-51T \| Microspline; Shimano Deore M6100 \| 12s	SRAM GX Eagle \| 12s; E13 ESpec Plus 165mm \| SRAM X-Sync Eagle 34T EMTB; SRAM GX Eagle 12s Single Click; SRAM PG1230 \| 12s \| 11-50T \| HG; SRAM GX Eagle \| 12s
Wheels	V2 Comp \| 36mm inner \| TR	Front: RaceFace Aeffect R30 29 Boost 110x15 \| 30mm inner / Rear: RaceFace Aeffect R30 29er B148x12 HG \| 30mm inner EMTB
Tyres	Front: Maxxis Minion DHF \| 29x2.6WT \| 3C MaxxTerra Exo+ TR / Rear: Maxxis Minion DHRII \| 29x2.6WT \| 3C MaxxTerra Exo+ TR	Front: Maxxis Minion DHF \| 29x2.5WT \| 3C MaxxTerra Exo+ TR / Rear: Maxxis Minion DHRII \| 29x2.4WT \| 3C MaxxGrip DoubleDown TR
Weight	24.9 kg	24.7 kg
Price	$7,599	$8,529
