E-Troy Lite 2024
How current the bike is — newer chassis, motor and battery score higher. 10 = brand-new, 0 = legacy.
The 2024 E-Troy Lite is Devinci's made-in-Canada lightweight take on its E-Troy platform: an aluminium, mixed-wheel trail bike running 150 mm of Split Pivot rear travel and a 160 mm fork. Where the standard E-Troy uses Bosch's full-power CX, the Lite drops in the Performance Line SX (55 Nm, 600 W) with the slimline 400 Wh CompactTube battery, trading outright assistance for a sub-21 kg weight and a more natural, trail-bike feel.
Three builds were offered. The NX 12S (US$5,499) pairs a RockShox Yari fork and Deluxe Select shock with SRAM DB8 brakes and an NX mechanical drivetrain. The GX 12S (US$6,399) is the value sweet spot, stepping up to a Fox 36 Performance Elite fork, Float X shock, SRAM Code Bronze brakes (220/200 mm) and a GX mechanical drivetrain on RaceFace Aeffect wheels. The flagship GX AXS 12S (US$7,399) moves to RockShox Lyrik and Super Deluxe Ultimate suspension, Magura MT5 brakes and a wireless SRAM GX Eagle Transmission, dropping to a claimed 19.5 kg.
Geometry is aggressive for a lightweight assist bike: a slack 63.6 degree head angle, steep effective seat angles (around 77.5 to 77.9 degrees), short 438 mm chainstays across all sizes and 20 mm reach jumps from 441 mm (S) to 501 mm (XL). The result is a stable, planted ride that rewards speed, with a relatively low stack that keeps the front end weighted.
The E-Troy Lite is discontinued; Devinci has since reorganised its e-mountain range, leaving the SX-powered Lite as a one-generation lightweight option in the line-up.
Geometry · hover a row to highlight the measurement on the bike
| S | M | L | XL | |
|---|---|---|---|---|
| Reach | 441 mm | 461 mm | 481 mm | 501 mm |
| Stack | 608 mm | 617 mm | 626 mm | 635 mm |
| Seattube | 400 mm | 420 mm | 460 mm | 495 mm |
| Chainstay | 438 mm | 438 mm | 438 mm | 438 mm |
| Headtube Angle | 63.6° | 63.6° | 63.6° | 63.6° |
| Seattube Angle (eff) | 77.9° | 77.8° | 77.6° | 77.5° |
| Wheelbase | 1216 mm | 1240 mm | 1264 mm | 1289 mm |
| Headtube | 95 mm | 105 mm | 115 mm | 125 mm |
| BB Height | 346 mm | 346 mm | 346 mm | 346 mm |
| Standover | 740 mm | 740 mm | 740 mm | 740 mm |
| Front Centre | 778 mm* | 802 mm* | 826 mm* | 851 mm* |
Trims · 3
GX 12S | GX AXS 12S | NX 12S | |
|---|---|---|---|
| Motor | Bosch Performance Line SX · 55 Nm · all trims | ||
| Battery | Bosch CompactTube 400 · 400 Wh · all trims | ||
| Travel F/R | 160/150 mm · all trims | ||
| Frame | Aluminium · all trims | ||
| Fork | Fox 36 PSE | Grip2 | 29 | 160 | 110x15 | 44OS | RockShox Lyrik Ultimate, DebonAir spring, 35mm stanchions, 44mm offset, 160mm | RockShox Yari | RC | Db | 29 | 160mm | 110x15 | 42Os | 2Token |
| Shock | Fox Float X Performance Elite | RockShox Super Deluxe Ultimate, trunnion mount, 185 x 55mm | Rockshox Deluxe Select Debonair | 185x55 Trunnion |
| Headset | FSA Orbit | 1.5 | Zero Stack | FSA Orbit 1.5 Zero Stack, ZS44 upper, ZS56 lower | FSA Orbit | 1.5 | Zero Stack |
| Stem | V2 Pro | B:35mm | L:40mm | 0° | Race Face Turbine R, 40mm length, 0° rise, 35mm bar clamp | V2 Pro | B:35mm | L:40mm | 0° |
| Handlebar | RaceFace Turbine R35 | B:35mm | R:35mm | W:800mm | Race Face Next R, 800mm width, 20mm rise, 35mm clamp | V2 Pro | B:35mm | R:30mm | W:800mm |
| Grips | Devinci Performance | w/lock-on | Devinci Performance, lock-on | Devinci | w/lock-on |
| Saddle | SDG BELAIR Max eMTB | SDG Bel-Air 3.0 | SDG BELAIR Max eMTB |
| Seatpost | SDG Tellis 31.6mm (SDG Tellis Matchmaker 1x lever) | SDG Tellis dropper, 31.6mm, SDG 1x remote lever | TranzX Dropper | 31.6mm | 1x Lever |
| Brakes | SRAM Code Bronze (front and rear) | Magura MT5 HCW, 4-piston; Magura Storm HC 203mm 6-bolt rotors | SRAM DB8 (front and rear) |
| Rear derailleur | SRAM GX Eagle | 12s | SRAM GX Eagle Transmission, 12-speed, AXS electronic wireless | SRAM NX Eagle | 12s |
| Crank | SRAM GX Bosch | 165mm; Sram X-Sync Eagle 34T EMTB chainring | SRAM X0 Eagle Transmission Alloy, 165mm; SRAM X0 Eagle Transmission 34T chainring | SRAM X1000 Bosch; Sram X-Sync Eagle 34T EMTB chainring |
| Shifters | SRAM GX Eagle 12s Single Click | SRAM Eagle Pod Controller, 12-speed, AXS electronic wireless | SRAM NX Eagle 12s |
| Cassette | SRAM PG1230 | 12s | 11-50T | HG | SRAM GX Eagle Transmission XS-1275, 12-speed, 10-52 tooth | SRAM PG1210-12s 11-50T |
| Chain | SRAM NX Eagle | 12s | SRAM GX Eagle Transmission Flattop, 12-speed | SRAM SX Eagle | 12s |
| Drivetrain | SRAM GX Eagle | 12s; SRAM GX Bosch | 165mm; Sram X-Sync Eagle 34T EMTB chainring; SRAM GX Eagle 12s Single Click; SRAM PG1230 | 12s | 11-50T | HG; SRAM NX Eagle | 12s | SRAM GX Eagle Transmission, 12-speed, AXS electronic wireless; SRAM X0 Eagle Transmission Alloy, 165mm; SRAM X0 Eagle Transmission 34T chainring; SRAM Eagle Pod Controller, 12-speed, AXS electronic wireless; SRAM GX Eagle Transmission XS-1275, 12-speed, 10-52 tooth; SRAM GX Eagle Transmission Flattop, 12-speed | SRAM NX Eagle | 12s; SRAM X1000 Bosch; Sram X-Sync Eagle 34T EMTB chainring; SRAM NX Eagle 12s; SRAM PG1210-12s 11-50T; SRAM SX Eagle | 12s |
| Wheels | Front: RaceFace Aeffect R30 29 Boost110x15 | 30mm inner; Rear: RaceFace Aeffect R30 27.5 B148x12 HG | 30mm inner EMTB | Race Face ARC30, 30mm inner width, tubeless ready (Race Face Vault hubs, XD driver) | — |
| Tyres | Front: Maxxis Assegai | 29x2.5WT | 3C | Exo | TR | MaxxTerra; Rear: Maxxis Minion DHRII | 27.5x2.4WT | 3C | Exo+ | TR | MaxxTerra | Front: Maxxis Minion DHF, 3C MaxxTerra, EXO, TR, 29 x 2.5 WT; Rear: Maxxis Dissector, 3C MaxxTerra, EXO+, TR, 27.5 x 2.4 WT | Front: Maxxis Assegai | 29x2.5WT | 3C | Exo | TR | MaxxTerra; Rear: Maxxis Minion DHRII | 27.5x2.4WT | 3C | Exo+ | TR | MaxxTerra |
| Weight | 20.2 kg | 19.5 kg | 20.5 kg |
