Canyon

Grand Canyon:ON 2024

Discontinued✎Full Power · Cross-CountryLegacy · 1.6/10iFreshness 1.6/10
How current the bike is — newer chassis, motor and battery score higher. 10 = brand-new, 0 = legacy.

Motor

Bosch Performance Line CX Gen 4 · 85Nm · 600W↗

Battery

Bosch PowerTube 750 · 750Wh

Travel F/R

120mm / —

Wheels

29F / 29R✎

Frame

Aluminium✎

Weight

23.3 kg

Price

From £3,099

View the Canyon Grand Canyon:ON on Canyon’s site

Canyon Grand Canyon:ON 2024

From £3,099

The 2024 Grand Canyon:ON is Canyon's aluminium flagship hardtail eMTB, built around a Bosch Performance Line CX motor (85 Nm) and a 750Wh PowerTube battery on a 29in, 120mm-fork platform. It is pitched as an all-day do-it-all adventure machine rather than a hard-charging trail weapon, and the geometry reflects that: a moderate 68-degree head angle, 76.5-degree effective seat angle, 460mm chainstays across all sizes and a low 309mm BB make for stable, planted handling rather than aggressive slackness.The three-trim ladder is tightly spaced. The 7 (£3,099) runs a RockShox Judy Silver TK fork, SRAM DB8 brakes, a Shimano Deore drivetrain and a rigid seatpost. The 8 (£3,499) is the sweet spot, adding a FOX 34 AWL fork, a Deore XT rear mech, a 12-speed Shimano Deore group and an Iridium dropper post. The 9 (£3,999) tops out with Magura CTE ABS braking and a fuller XT build. All three share the same frame, motor, 750Wh battery and 23 to 24kg claimed weights, so the spend goes on suspension, brakes and drivetrain rather than ride platform.This model year is discontinued. Canyon has since relaunched the line as the Grand Canyon:ON AL (7/8/9), moving to the latest Bosch Performance Line CX with higher peak output and a larger battery option while keeping the same do-it-all hardtail brief. British buyers seeking the 2024 bike will now find it only on the used market.

EMTB Forums verdict

The 2024 Grand Canyon:ON is Canyon's aluminium flagship hardtail eMTB, built around a Bosch Performance Line CX motor (85 Nm) and a 750Wh PowerTube battery on a 29in, 120mm-fork platform. It is pitched as an all-day do-it-all adventure machine rather than a hard-charging trail weapon, and the geometry reflects that: a moderate 68-degree head angle, 76.5-degree effective seat angle, 460mm chainstays across all sizes and a low 309mm BB make for stable, planted handling rather than aggressive slackness.

The three-trim ladder is tightly spaced. The 7 (£3,099) runs a RockShox Judy Silver TK fork, SRAM DB8 brakes, a Shimano Deore drivetrain and a rigid seatpost. The 8 (£3,499) is the sweet spot, adding a FOX 34 AWL fork, a Deore XT rear mech, a 12-speed Shimano Deore group and an Iridium dropper post. The 9 (£3,999) tops out with Magura CTE ABS braking and a fuller XT build. All three share the same frame, motor, 750Wh battery and 23 to 24kg claimed weights, so the spend goes on suspension, brakes and drivetrain rather than ride platform.

This model year is discontinued. Canyon has since relaunched the line as the Grand Canyon:ON AL (7/8/9), moving to the latest Bosch Performance Line CX with higher peak output and a larger battery option while keeping the same do-it-all hardtail brief. British buyers seeking the 2024 bike will now find it only on the used market.

Geometry read

What the numbers mean on the trail

Computed from this bike's geometry, spec and build kit — reach, wheelbase, chainstay, head and seat angles, travel, motor, weight and the fork/tyre/brake spec — and worked out per size, because a fixed chainstay can make an S and an XL feel very different.

Size

Descending

Steeper 68° and shorter travel — happiest descending smooth, flowy trail rather than properly rough or steep terrain.

Playfulness

A fair bit of pop, but happiest on flowing trail rather than trials moves.

Size balance

Rear-long with a planted front in L (FC:RC 1.69) — easy to weight the front and quick to turn, though it can feel light at the back at real speed.

Technical climbing

Bosch Performance Line CX Gen 4 and a steep 76.5° seat angle keep the weight planted over the front — a proper winch. 600W of peak power and 85Nm of torque — a strong full-power motor.

Best suited toAll-round trail riding across mixed terrain.

No single standout trait — a balanced, versatile bike.

Watch out forNot built for serious descending — happier on flow than in the rough and steep.

Fine at trail pace; it'll feel out of its depth on properly rough, steep tracks.

How it stacks up vs other Full Power · Cross-Country bikes (from 106 bikes in the database)

Weight23.3 kgabout average weight

Battery750 Wh53 Wh above average

Motor torque85 Nm8 Nm below average

Value for money67/100from £3,099 · most Bosch Performance Line CX Gen 4 bikes ~£3,499

Computed from geometry + spec, not a paid review. Scores are guidance, not gospel.

Paste into any thread to embed this live, interactive panel.

💬 Forum discussion

Canyon with AVINOX!

14 replies · 3.2k views · last reply 2 days ago

Join the discussion →

Geometry · hover a row to highlight the measurement on the bike

	S	M	L	XL
Reach	425 mm	450 mm	475 mm	500 mm
Stack	647 mm	661 mm	675 mm	688 mm
Seattube	395 mm	440 mm	485 mm	540 mm
Chainstay	460 mm	460 mm	460 mm	460 mm
Headtube Angle	68°	68°	68°	68°
Seattube Angle (eff)	76.5°	76.5°	76.5°	76.5°
Wheelbase	1175 mm	1206 mm	1236 mm	1267 mm
Headtube	115 mm	130 mm	145 mm	160 mm
BB Height	309 mm	309 mm	309 mm	309 mm
Standover	782 mm	792 mm	823 mm	837 mm
Front Centre	715 mm*	746 mm*	776 mm*	807 mm*
FC:RC	1.55	1.62	1.69	1.75

Trims · 3

	7 £3,099	8 £3,499	9 £3,999
Motor	Bosch Performance Line CX Gen 4 · 85 Nm · all trims
Battery	Bosch PowerTube 750 · 750 Wh · all trims
Travel F/R	120/? mm · all trims
Frame	Aluminium · all trims
Fork	RockShox Judy Silver TK, Travel: 120 mm	FOX 34 AWL, Axle: 15x110 mm, Stanchion: 34 mm, Travel: 120 mm, Offset: 51 mm	FOX 34 AWL, Travel: 120 mm
Stem	Canyon:ON ST0031, Length: 45 mm	Canyon:ON ST0031, Length: 45 mm, Clamp: 35.0 mm	Canyon:ON ST0031, Length: 45 mm, Clamp: 35 mm
Handlebar	Canyon:ON HB0056 Riser bar, Aluminium, Width: 760 mm, Rise: 20 mm	Canyon:ON HB0056 Riser bar, Aluminium, Clamp: 35.0 mm, Width: 760 mm, Rise: 20 mm	Canyon:ON HB0056 Riser bar, Clamp: 35 mm, Width: 760 mm, Rise: 20 mm
Saddle	Fizik Terra Alpaca X5	Fizik Terra Alpaca X5, 230 g	Fizik Terra Alpaca X5, 230 g
Seatpost	SP HL C255 400, Aluminium, Clamp diameter: 30.9 mm	Iridium Dropper Post, Aluminium, Clamp: 30.9 mm, 567 g	Iridium Dropper Post, Aluminium, Clamp: 30.9 mm, 580 g
Brakes	SRAM DB8 Hydraulic Disc	Shimano Deore M6120 (front) \| Shimano Deore M6100 (rear) Hydraulic Disc	Magura CTE ABS, 4-piston Hydraulic Disc
Rear derailleur	Shimano Deore M6100, long cage	Shimano Deore XT M8100, long cage	Shimano Deore XT M8100, long cage
Crank	FSA 745 E-Bike Crank for Bosch Gen4	FSA 745 E-Bike Crank for Bosch Gen4	FSA E-Bike Crank for Bosch Gen4
Shifters	Shimano Deore M6100	Shimano Deore M6100 12s	Shimano Deore XT
Cassette	Shimano Deore M6100, 10-51T, 12-speed	Shimano Deore M6100, 10-51T, 12-speed	10-51T, 12-speed
Chain	—	Shimano CN-M6100	—
Drivetrain	Shimano Deore M6100, long cage; FSA 745 E-Bike Crank for Bosch Gen4; Shimano Deore M6100; Shimano Deore M6100, 10-51T, 12-speed	Shimano Deore XT M8100, long cage; FSA 745 E-Bike Crank for Bosch Gen4; Shimano Deore M6100 12s; Shimano Deore M6100, 10-51T, 12-speed; Shimano CN-M6100	Shimano Deore XT M8100, long cage; FSA E-Bike Crank for Bosch Gen4; Shimano Deore XT; 10-51T, 12-speed
Wheels	Aluminium	RODI TRYP30 EVO, Center Lock	Aluminium
Tyres	Schwalbe Nobby Nic Performance 29", 2.6"	Schwalbe Nobby Nic Performance 2.6"	Schwalbe Nobby Nic Performance 2.6", Tubeless Ready
Weight	23.3 kg	23.5 kg	24.2 kg
Price	£3,099	£3,499	£3,999
