Canyon

Grand Canyon:ON 2023

Discontinued✎Full Power · Cross-CountryLegacy · 1/10iFreshness 1/10
How current the bike is — newer chassis, motor and battery score higher. 10 = brand-new, 0 = legacy.

Full-power alloy hardtail with a large battery at a low price

Motor

Bosch Performance Line CX Gen 4 · 85Nm · 600W↗

Battery

Bosch PowerTube 750 · 750Wh

Travel F/R

120mm / —

Wheels

29F / 29R✎

Frame

Aluminium✎

Weight

22.5 kg

Price

From £3,199

View the Canyon Grand Canyon:ON on Canyon’s site

Canyon Grand Canyon:ON 2023

From £3,199

The 2023 Grand Canyon:ON is Canyon's alloy e-hardtail: a 29er with a 120 mm fork, full-power Bosch Performance Line CX motor (85 Nm) and an integrated, removable PowerTube battery. It sits in the same value XC/trail-hardtail class as a Trek Marlin+, pitched at developing riders and all-day exploring rather than aggressive descending.The geometry is deliberately middle-of-the-road for a modern hardtail: a 68 degree head angle, 76.5 degree effective seat angle, 460 mm chainstays and reach from 425 mm (S) to 500 mm (XL). It is stable and easy to manage rather than racy, which suits the bike's all-rounder brief. Frame storage extras (mudguard, rack, kickstand) are catered for, reinforcing the commute-and-trail flexibility.Trim value is strong by direct-sale standards. The PS3,199 Grand Canyon:ON 7 pairs a RockShox Judy Silver fork, SRAM DB8 brakes and a 625 Wh battery (750 Wh optional) but skips a dropper. The PS3,649 Grand Canyon:ON 8 steps up to a FOX 34 AWL fork, an Iridium dropper, Shimano XT shifting and the 750 Wh pack. The PS4,149 Grand Canyon:ON 9 adds Magura CTE brakes with Bosch ABS and GPS tracking, all sharing the same Deore 12-speed drivetrain and Schwalbe Nobby Nic 2.6in tyres.This model year is discontinued. Canyon later overhauled the Grand Canyon hardtail platform, so the 2023 alloy Bosch :ON is best viewed as a used or run-out buy rather than a current option.

EMTB Forums verdict

The 2023 Grand Canyon:ON is Canyon's alloy e-hardtail: a 29er with a 120 mm fork, full-power Bosch Performance Line CX motor (85 Nm) and an integrated, removable PowerTube battery. It sits in the same value XC/trail-hardtail class as a Trek Marlin+, pitched at developing riders and all-day exploring rather than aggressive descending.

The geometry is deliberately middle-of-the-road for a modern hardtail: a 68 degree head angle, 76.5 degree effective seat angle, 460 mm chainstays and reach from 425 mm (S) to 500 mm (XL). It is stable and easy to manage rather than racy, which suits the bike's all-rounder brief. Frame storage extras (mudguard, rack, kickstand) are catered for, reinforcing the commute-and-trail flexibility.

Trim value is strong by direct-sale standards. The PS3,199 Grand Canyon:ON 7 pairs a RockShox Judy Silver fork, SRAM DB8 brakes and a 625 Wh battery (750 Wh optional) but skips a dropper. The PS3,649 Grand Canyon:ON 8 steps up to a FOX 34 AWL fork, an Iridium dropper, Shimano XT shifting and the 750 Wh pack. The PS4,149 Grand Canyon:ON 9 adds Magura CTE brakes with Bosch ABS and GPS tracking, all sharing the same Deore 12-speed drivetrain and Schwalbe Nobby Nic 2.6in tyres.

This model year is discontinued. Canyon later overhauled the Grand Canyon hardtail platform, so the 2023 alloy Bosch :ON is best viewed as a used or run-out buy rather than a current option.

Geometry read

What the numbers mean on the trail

Computed from this bike's geometry, spec and build kit — reach, wheelbase, chainstay, head and seat angles, travel, motor, weight and the fork/tyre/brake spec — and worked out per size, because a fixed chainstay can make an S and an XL feel very different.

Size

Descending

A solid all-round descender (68° head angle, 120mm) — capable in the rough and steep without being an all-out bruiser.

Playfulness

Short 460mm rear and a lighter build — easy to pop, manual and throw around.

Size balance

Rear-long with a planted front in L (FC:RC 1.69) — easy to weight the front and quick to turn, though it can feel light at the back at real speed.

Technical climbing

Bosch Performance Line CX Gen 4 and a steep 76.5° seat angle keep the weight planted over the front — a proper winch. 600W of peak power and 85Nm of torque — a strong full-power motor.

Best suited toPlayful trail riding — jumps, pumps and tight, techy singletrack.

Easy to throw around; happiest when you're active on the bike.

Watch out forNo major red flags in the L geometry.

The numbers are well balanced for its category.

How it stacks up vs other Full Power · Cross-Country bikes (from 130 bikes in the database)

Weight22.5 kg1.2 kg lighter than average

Battery750 Wh63 Wh above average

Motor torque85 Nmabout average torque

Value for money63/100from £3,199 · most Bosch Performance Line CX Gen 4 bikes ~£3,499

Computed from geometry + spec, not a paid review. Scores are guidance, not gospel.

Paste into any thread to embed this live, interactive panel.

💬 Forum discussion

Canyon with AVINOX!

14 replies · 3.5k views · last reply 2 weeks ago

Join the discussion →

Geometry · hover a row to highlight the measurement on the bike

	S	M	L	XL
Reach	425 mm	450 mm	475 mm	500 mm
Stack	647 mm	661 mm	675 mm	688 mm
Seattube	395 mm	440 mm	485 mm	540 mm
Chainstay	460 mm	460 mm	460 mm	460 mm
Headtube Angle	68°	68°	68°	68°
Seattube Angle (eff)	76.5°	76.5°	76.5°	76.5°
Wheelbase	1175 mm	1206 mm	1236 mm	1267 mm
Headtube	115 mm	130 mm	145 mm	160 mm
BB Height	309 mm	309 mm	309 mm	309 mm
Standover	782 mm	792 mm	823 mm	837 mm
Front Centre	715 mm*	746 mm*	776 mm*	807 mm*
FC:RC	1.55	1.62	1.69	1.75

Trims · 3

	7 £3,199	8 £3,649	9 £4,149
Motor	Bosch Performance Line CX Gen 4 · 85 Nm · all trims
Battery	Bosch PowerTube 750 · 750 Wh · all trims
Travel F/R	120/? mm · all trims
Frame	Aluminium · all trims
Fork	RockShox Judy Silver 29, 120 mm, 30 mm stanchions, 15x110 Boost, 51 mm offset	FOX 34 AWL, 120 mm, 34 mm stanchions, 15x110 Boost, 51 mm offset	FOX 34 AWL, 120 mm, 34 mm stanchions, 15x110 Boost, 51 mm offset
Stem	Canyon:ON ST0031 E-MTB stem, 35 mm clamp, 45 mm length · all trims
Handlebar	Canyon:ON HB0056 Riser, alloy, 35 mm clamp, 760 mm width, 20 mm rise · all trims
Grips	Canyon Lock-On Grips · all trims
Saddle	Fizik Terra Alpaca X5 · all trims
Seatpost	Iridium rigid seatpost, 30.9 mm (no dropper on this trim)	Iridium Dropper Post, internal routing, 30.9 mm (125-170 mm travel by size)	Iridium Dropper Post, internal routing, 30.9 mm (125-170 mm travel by size)
Brakes	SRAM DB8 4-piston hydraulic disc; SRAM Centerline rotors 200 mm front / 180 mm rear	Shimano Deore M6120 (front, 4-piston) / Shimano Deore M6100 (rear, 2-piston); Shimano SM-RT30 203 mm front / Shimano MT200 180 mm rear rotors	Magura CTE ABS 4-piston hydraulic disc (Bosch ABS); Magura MDR-C 203 mm rotors front and rear
Rear derailleur	Shimano Deore M6100, 1x12, long cage	Shimano Deore XT M8100, 1x12, long cage	Shimano Deore XT M8100, 1x12, long cage
Crank	FSA 745 E-Bike Crank for Bosch Gen4 · all trims
Shifters	Shimano Deore M6100 12-speed · all trims
Cassette	Shimano Deore CS-M6100 12-speed, 10-51T · all trims
Chain	Shimano CN-M6100 12-speed · all trims
Drivetrain	Shimano Deore M6100, 1x12, long cage; FSA 745 E-Bike Crank for Bosch Gen4; Shimano Deore M6100 12-speed; Shimano Deore CS-M6100 12-speed, 10-51T; Shimano CN-M6100 12-speed	Shimano Deore XT M8100, 1x12, long cage; FSA 745 E-Bike Crank for Bosch Gen4; Shimano Deore M6100 12-speed; Shimano Deore CS-M6100 12-speed, 10-51T; Shimano CN-M6100 12-speed	Shimano Deore XT M8100, 1x12, long cage; FSA 745 E-Bike Crank for Bosch Gen4; Shimano Deore M6100 12-speed; Shimano Deore CS-M6100 12-speed, 10-51T; Shimano CN-M6100 12-speed
Wheels	RODI TRYP30 EVO, Center Lock, 29in	RODI TRYP30 EVO, Center Lock, 29in	Rodi Tryp 30, 29in (15x110 front / 12x148 rear)
Tyres	Schwalbe Nobby Nic Performance 29x2.6in · all trims
Weight	22.5 kg	23.8 kg	24.5 kg
Price	£3,199	£3,649	£4,149
