BULLS

EVO CX AM 2026

Current✎Full Power · TrailCurrent · 8.3/10iFreshness 8.3/10
How current the bike is — newer chassis, motor and battery score higher. 10 = brand-new, 0 = legacy.

Full-power alloy trail all-rounder with 800Wh for genuinely long days

Motor

Bosch Performance Line CX Gen 5 · 100Nm · 600W↗

Battery

Bosch PowerTube 800 · 800Wh

Travel F/R

140/140mm

Wheels

29F / 29R✎

Frame

Aluminium✎

Weight

26.4 kg

Price

From €3,499

View the BULLS EVO CX AM on BULLS’s site

BULLS EVO CX AM 2026

The BULLS EVO CX AM is a value-focused aluminium trail e-MTB built on a Mono-Link swingarm with 140mm of travel front and rear. Both builds run Bosch's Performance Line CX Gen 5 (Smart System) motor, delivered here in a 100Nm / 600W tune, paired with a Bosch Purion 200 display and a 10-speed Shimano CUES LinkGlide drivetrain (RD-U6000 mech, CS-LG300 11-48T cassette). It is a deliberately affordable, do-it-all package rather than a high-end race bike.The two trims are more different than their names suggest. The AM 2 (EUR 3,999) is the flagship: 29in wheels, an 800Wh Bosch PowerTube, a RockShox 35 Gold RL air fork and a 100mm RUMBLE Escalator dropper, with a claimed weight of 26.8kg. The AM 1 (EUR 3,499) steps down to 27.5in wheels, a smaller 540Wh PowerTube, a Lytro 34 Air fork and a 75mm dropper, at a claimed 26.4kg. Both share the SR Suntour Edge X-2CR shock, Schwalbe Smart Sam tyres, BULLS DDM-30 rims, Shimano BR-MT200-class hydraulic brakes on 180mm rotors and the RUMBLE Altimate cockpit.Geometry, published by BULLS for the 29in AM 2, is middle-of-the-road trail: a 66-degree head angle and 76-degree effective seat angle right across the range, 445mm chainstays at every size, and reach growing from 438mm on the S to 494mm on the XL. This is a sensible, price-led family aimed at trail riding and off-road touring rather than aggressive enduro use.

EMTB Forums verdict

The BULLS EVO CX AM is a value-focused aluminium trail e-MTB built on a Mono-Link swingarm with 140mm of travel front and rear. Both builds run Bosch's Performance Line CX Gen 5 (Smart System) motor, delivered here in a 100Nm / 600W tune, paired with a Bosch Purion 200 display and a 10-speed Shimano CUES LinkGlide drivetrain (RD-U6000 mech, CS-LG300 11-48T cassette). It is a deliberately affordable, do-it-all package rather than a high-end race bike.

The two trims are more different than their names suggest. The AM 2 (EUR 3,999) is the flagship: 29in wheels, an 800Wh Bosch PowerTube, a RockShox 35 Gold RL air fork and a 100mm RUMBLE Escalator dropper, with a claimed weight of 26.8kg. The AM 1 (EUR 3,499) steps down to 27.5in wheels, a smaller 540Wh PowerTube, a Lytro 34 Air fork and a 75mm dropper, at a claimed 26.4kg. Both share the SR Suntour Edge X-2CR shock, Schwalbe Smart Sam tyres, BULLS DDM-30 rims, Shimano BR-MT200-class hydraulic brakes on 180mm rotors and the RUMBLE Altimate cockpit.

Geometry, published by BULLS for the 29in AM 2, is middle-of-the-road trail: a 66-degree head angle and 76-degree effective seat angle right across the range, 445mm chainstays at every size, and reach growing from 438mm on the S to 494mm on the XL. This is a sensible, price-led family aimed at trail riding and off-road touring rather than aggressive enduro use.

Geometry read

What the numbers mean on the trail

Computed from this bike's geometry, spec and build kit — reach, wheelbase, chainstay, head and seat angles, travel, motor, weight and the fork/tyre/brake spec — and worked out per size, because a fixed chainstay can make an S and an XL feel very different.

Size

Descending

A solid all-round descender (66° head angle, 140mm) — capable in the rough and steep without being an all-out bruiser.

Playfulness

More planted than poppy — better on steep terrain than tight, fiddly singletrack.

Size balance

Rear-long with a planted front in L (FC:RC 1.80) — easy to weight the front and quick to turn, though it can feel light at the back at real speed.

Technical climbing

Bosch Performance Line CX Gen 5 and a steep 76° seat angle keep the weight planted over the front — a proper winch. 600W of peak power and 120Nm of torque — among the most powerful e-bike motors made.

Best suited toBig-day all-rounders who climb a lot and still descend hard.

Strong up and composed down — a do-it-all, not a specialist.

Watch out forNo major red flags in the L geometry.

The numbers are well balanced for its category.

How it stacks up vs other Full Power · Trail bikes (from 271 bikes in the database)

Weight26.4 kg3.4 kg heavier than average

Battery800 Wh95 Wh above average

Motor torque100 Nmabout average torque

Computed from geometry + spec, not a paid review. Scores are guidance, not gospel.

Paste into any thread to embed this live, interactive panel.

Geometry · hover a row to highlight the measurement on the bike

	S	M	L	XL
Reach	438 mm	450 mm	472 mm	494 mm
Stack	628 mm	640 mm	654 mm	667 mm
Seattube	400 mm	430 mm	470 mm	510 mm
Chainstay	445 mm	445 mm	445 mm	445 mm
Headtube Angle	66°	66°	66°	66°
Seattube Angle (eff)	76°	76°	76°	76°
Wheelbase	1204 mm	1220 mm	1245 mm	1271 mm
Headtube	110 mm	120 mm	130 mm	140 mm
BB Height	344 mm	340 mm	336 mm	332 mm
Front Centre	759 mm*	775 mm*	800 mm*	826 mm*
FC:RC	1.71	1.74	1.80	1.86

Trims · 2

	AM 1 €3,499	AM 2 €3,999
Motor	Bosch Performance Line CX Gen 5 · 100 Nm · all trims
Battery	Bosch PowerTube 800 · 800 Wh · all trims
Travel F/R	140/140 mm · all trims
Frame	Aluminium · all trims
Fork	Lytro 34 Air Boost 2CR DS 15AH2-110, 140 mm	RockShox 35 Gold RL, 1.8 Steerer, 140 mm, air
Shock	SR SUNTOUR EDGE X-2CR, 140 mm · all trims
Headset	ACROS AZX-279, ZS56/28.6/ZS66/40	ACROS AZX-274, ZS56/28.6/ZS66/46
Stem	RUMBLE Altimate · all trims
Handlebar	RUMBLE Altimate 35 Riser · all trims
Saddle	BULLS MTB-Sport · all trims
Seatpost	RUMBLE Escalator 34.9 mm + SL-MT500-L Hub 75 mm (dropper)	RUMBLE Escalator 34.9 mm + SL-MT500-L Hub 100 mm (dropper)
Brakes	Shimano BR-MT200 hydraulic disc · all trims
Rear derailleur	Shimano CUES RD-U6000 · all trims
Crank	SAMOX EC-53 · all trims
Shifters	Shimano CUES SL-U6000 · all trims
Cassette	Shimano CUES CS-LG300-10, 11-48T · all trims
Chain	Shimano LinkGlide CN-LG500 · all trims
Drivetrain	Shimano CUES RD-U6000; SAMOX EC-53; Shimano CUES SL-U6000; Shimano CUES CS-LG300-10, 11-48T; Shimano LinkGlide CN-LG500 · all trims
Wheels	BULLS DDM-30 · all trims
Tyres	Schwalbe Smart Sam K-Guard · all trims
Weight	26.4 kg	26.8 kg
Price	€3,499	€3,999
