New switch SHIMANO SW-EN600-L STEPS , but what cable to use?

volts

Active member
May 15, 2018
331
254
DK
So I have ordered the



SHIMANO SW-EN600-L STEPS

but I still don't really know what cable to get for my Orbea Rise for it to work.
I plan on replacing the EW-100 and the old mode switcher and use the new one instead.
As I understand it there are two different kinds of cables but it's difficult to find out what kind of cable I need. I plan on connecting it via the junction box near the headset with an cable that runs from there and all the way to the switch unit.

Any help appreciated.


volts

Active member
May 15, 2018
331
254
DK
It is not about the cable, the switch is only for the new EP6.

If cable, the switch has the small SD-300 cable, the box the SD-50.
Hmm do you know for sure that it won't work with EP800? I don't see a reason for it not working with EP800.
It certainly also works with EP801 since it's sold on the 2023 Rise with that motor.


MBj1703

Active member
Jul 15, 2021
147
81
Germany, near Munich
It is discussed many time here and in other forums. The new switches, buttons, etc. are not wokring with the "old" EP8 Motor system due to the new CAN bus.

I would love, if it would work, I want the new display and power button.


volts

Active member
May 15, 2018
331
254
DK
It is discussed many time here and in other forums. The new switches, buttons, etc. are not wokring with the "old" EP8 Motor system due to the new CAN bus.

I would love, if it would work, I want the new display and power button.
I guess I don't follow other forums and I haven't seen it here. I specifically looked for it here in the Shimano steps forum and didn't see it. But that's sad to hear, I guess I will have to return it when it arrives then. Searching google for SHIMANO SW-EN600-L STEPS EP800 compatibility also does not return anything useful, so I don't really think it's that obvious.


Seyed

Member
Jun 19, 2020
3
0
Toronto
I have already connected SW-EN600-L (disconnected SW-EM800) to SC-Em800 and EP800 Motor. It didn't work. Turns on and immediately goes off. SC-EM800 like SC-E8000 has power button and Bluetooth and SC-EN600 and SC-EN610 haven't Power button and Bluetooth. Power button and Bluetooth are located in SW-EN600-L. It's expected after connecting SW-EN600-L to SC-EM800 the system hangs because there are two power button and two Bluetooth and it's against etube project protocols. I have ordered SC-EN610 to test and connect to SW-EN600-L and to EP800. Waiting to recieve in next days. The new firmware updates for SW-EM800 and SC-EM800 have made them compatible with EP801. If they are compatible to newer CAN version why shouldn't the new display and switch be compatible to old CAN? SW-EN600-R, SW-M8150-R and RD-M8150 are all compatible with EP800, EP801 and EP6. CAN compability makes no sense.

Last edited:

SEBA

Member
Sep 11, 2019
266
98
French Provence High Alps
I have already connected SW-EN600-L (disconnected SW-EM800) to SC-Em800 and EP800 Motor. It didn't work. Turns on and immediately goes off. SC-EM800 like SC-E8000 has power button and Bluetooth and SC-EN600 and SC-EN610 haven't Power button and Bluetooth. Power button and Bluetooth are located in SW-EN600-L. It's expected after connecting SW-EN600-L to SC-EM800 the system hangs because there are two power button and two Bluetooth and it's against etube project protocols. I have ordered SC-EN610 to test and connect to SW-EN600-L and to EP800. Waiting to recieve in next days. The new firmware updates for SW-EM800 and SC-EM800 have made them compatible with EP801. If they are compatible to newer CAN version why shouldn't the new display and switch be compatible to old CAN? SW-EN600-R, SW-M8150-R and RD-M8150 are all compatible with EP800, EP801 and EP6. CAN compability makes no sense.
what ?!

sw m8150 r is compatible with ep800 ?


Seyed

Member
Jun 19, 2020
3
0
Toronto
what ?!

sw m8150 r is compatible with ep800 ?
I have ordered, I hope it would be compatible. Technically it should be compatible with ep800. No one knows but I hope. When RD-m9050 came to market many people told it's not compatible with e8000 motor and shimano compability charts still shows rd-m8050 is compatible and not RD-M9050. Technically I have been using RD-M9050 and SW-M9050 on E8000 and EP800. I hope SW-M8150 would work on EP800 and RD-M9050.


SEBA

Member
Sep 11, 2019
266
98
French Provence High Alps
I have ordered, I hope it would be compatible. Technically it should be compatible with ep800. No one knows but I hope. When RD-m9050 came to market many people told it's not compatible with e8000 motor and shimano compability charts still shows rd-m8050 is compatible and not RD-M9050. Technically I have been using RD-M9050 and SW-M9050 on E8000 and EP800. I hope SW-M8150 would work on EP800 and RD-M9050.
on shimano pdf not compatible


MTB_Belgium

New Member
Jun 23, 2023
1
0
Belgium
I cannot see why this wouldn't work since there is even an adapter from shimano to go from one cable to the other?


But I think you have to disconnect the original power connector and the original bluetooth module on the rise so there is only one for both options

Like to hear more thoughts or if anyone succeeded


SEBA

Member
Sep 11, 2019
266
98
French Provence High Alps
I cannot see why this wouldn't work since there is even an adapter from shimano to go from one cable to the other?


But I think you have to disconnect the original power connector and the original bluetooth module on the rise so there is only one for both options

Like to hear more thoughts or if anyone succeeded
it is not working because there's probably a list of authorized components inside the firmware of each components or computer display ...

the adapter doesnt mean the new en600 shifter is compatible

ep801 mandatory to use 12s di2 and that's all


SEBA

Member
Sep 11, 2019
266
98
French Provence High Alps
I have ordered, I hope it would be compatible. Technically it should be compatible with ep800. No one knows but I hope. When RD-m9050 came to market many people told it's not compatible with e8000 motor and shimano compability charts still shows rd-m8050 is compatible and not RD-M9050. Technically I have been using RD-M9050 and SW-M9050 on E8000 and EP800. I hope SW-M8150 would work on EP800 and RD-M9050.
any news ?
