Other Levo Gen1 vs Gen2 vs Gen3?

figment

New Member
Oct 23, 2023
5
2
USA
I recently purchased a 2017 Levo FSR, and a 2021 Levo frame and want to know what current 2023 year model parts are compatible (if any).

I'm not even sure how to identify a Gen1, Gen2 or Gen3. There doesn't seem to be any information on the Specialized website. It seems they expect people to just know?

Does anyone have a comprehensive comparison between the Levo "generations"?
thanks!


Zimmerframe

MUPPET
Subscriber
Jun 12, 2019
13,978
20,727
Brittany, France
For quick visual identification :

Gen1 had a sort of slope above the motor.
Gen2 was flat above the motor
Gen3 had the slope back

Gen 1 used Brose 1.2/1.3
Everything else used Brose 2.1 Mag S (though called 2.2 on Gen3).

These are not interchangable, but the 1.3 is quieter and with 5.4.2 firmware or above, will pull 20 amps, so is more powerful.

Gen1 uses a different battery to it's siblings.

Other than that, pretty much every part is different, though forks, wheels and so on are potentially interchangable.

Gen4 is different again, but not out yet.


RebornRider

Well-known member
May 31, 2019
628
640
NorCal USA
I was thinking that everything an owner would likely swap; wheels, tires, fork, shock, derailleur, cranks/pedals, stem, handlebar, dropper, saddle, would work across all generations. Unless there is some 27.5/29 incompatibility.

Everything that makes a Spesh a Spresh; frame parts, motor, battery, would have to be researched before swapping.

I realize we're saying essentially the same thing, but with different emphasis. :)


Zimmerframe

MUPPET
Subscriber
Jun 12, 2019
13,978
20,727
Brittany, France
Gen1 came around July 2015 ?



Gen 2 - September 2018 ish ..



Gen3 Was March 2021.



jamtb

Member
Nov 21, 2021
13
5
Grove City, Pennsylvania
To start at the beginning you can tell the difference on these points.
Gen 1 has Green lighs on the left side of the battery on the Frame.
Gen 2 has a TCO on the top of the Frame with lights on it.
Gen 3 Comps etc, have the same TCU, but the battery connector is different. Gen 3 has a little door that opens.
Gen 3 higher end bikes, have the Mastermind TCU with a screen and and numbers etc.
As for parts, very few Gen 2 and 3 parts will interchange. Many Gen2 and Gen 3 are the same. Battery (but with a different cover), Motor, etc, but again a lot depends on what model Gen2, a Comp uses Shimano compents but higher end uses Sram. Both have FOX shupension but different levels.
Gen 3 bikes are a littl emore slack then the Gen 2 bikes. In the ends lots of differences.


thewrx

Member
Sep 4, 2019
187
71
US
I recently purchased a 2017 Levo FSR, and a 2021 Levo frame and want to know what current 2023 year model parts are compatible (if any).

I'm not even sure how to identify a Gen1, Gen2 or Gen3. There doesn't seem to be any information on the Specialized website. It seems they expect people to just know?

Does anyone have a comprehensive comparison between the Levo "generations"?
thanks!
I tried that, good luck, but expect crickets.


figment

New Member
Oct 23, 2023
5
2
USA
Agreed, this shouldn't be the case. Manufacturers should openly provide schematics and parts lists.
Inbike.com is helping me, there is very little information out there. I'm collecting everything I can and will start a new post containing all the verifed information I have collected.
