Descending
56
A solid all-round descender (66° head angle, 152mm) — capable in the rough and steep without being an all-out bruiser.
Rotwild
R.X750 2022
Discontinued✎Full Power · TrailLegacy · 0.2/10iFreshness 0.2/10
How current the bike is — newer chassis, motor and battery score higher. 10 = brand-new, 0 = legacy.
How current the bike is — newer chassis, motor and battery score higher. 10 = brand-new, 0 = legacy.
Quiet Brose-powered full-carbon all-mountain bike for long trail days
Motor
Brose Drive S Mag · 90Nm · 560W↗
Battery
Rotwild IPU750 750Wh
Travel F/R
150/152mm
Wheels
MX (29F / 27.5R)✎
Frame
Carbon front, aluminium rear / Full carbon
Weight
—
Price
From €7,499
EMTB Forums verdict
The R.X750 was the flagship of Rotwild's 'Big Mountain' category for 2022: a handmade full carbon 150/152 mm mixed-wheel eMTB built around the Brose Drive S Mag motor and the brand's own quick release IPU750 750 Wh battery. It sat between the lighter all-mountain R.X375 and the enduro R.E750 in the German range, pitched at technical alpine climbing and descending.
All three trims shared the frame, motor, battery and Schwalbe Magic Mary/Hans Dampf tyre pairing, so the money went on suspension and drivetrain. The Core (7,499 euro) ran Fox Performance dampers, Shimano XT shifting and Magura MT5 brakes; the Pro (8,999 euro) added XT four-piston brakes, DT Swiss HX 1501 wheels and an Eightpins H01 dropper; the Ultra (11,999 euro) topped out with Factory Kashima suspension, full XTR, carbon DT Swiss HXC 1501 wheels and the longer stroke Eightpins NGS 2 post.
Geometry is moderate rather than radical, with a 66 degree head angle, 445 mm chainstays and a 437 mm reach in M, plus a usefully low 750 mm standover across all four sizes. The bike is discontinued: Rotwild relaunched the R.X750 name on a redesigned platform for 2023.
Geometry read
What the numbers mean on the trail
Computed from this bike's geometry, spec and build kit — reach, wheelbase, chainstay, head and seat angles, travel, motor, weight and the fork/tyre/brake spec — and worked out per size, because a fixed chainstay can make an S and an XL feel very different.
Size
Playfulness
62
A fair bit of pop, but happiest on flowing trail rather than trials moves.
Size balance
98
Rear-long with a planted front in L (FC:RC 1.78) — easy to weight the front and quick to turn, though it can feel light at the back at real speed.
Technical climbing
67
Climbs well — a 74° seat keeps the front planted. 560W of peak power and 90Nm of torque — a strong full-power motor.
No single standout trait — a balanced, versatile bike.
The numbers are well balanced for its category.
How it stacks up vs other Full Power · Trail bikes (from 271 bikes in the database)
Battery750 Whabout average capacity
Motor torque90 Nm8 Nm below average
Computed from geometry + spec, not a paid review. Scores are guidance, not gospel.
💬 Forum discussion
Rotwild RX750 Ultra - Brose Mag S, 750WH
12 replies · 11.4k views · last reply 80 months ago
Join the discussion →
“Looks like its not only Specilized bringing it with the new Mag S, Rotwild coming in with all guns blazing on this one. 22.6 KG, mixed size DT Swiss carbon wheels, massive battery, full carbon frame, 12 speed XTR, Eightpins frame…”
— R120 · ♥ 14 · most-liked post
Geometry · hover a row to highlight the measurement on the bike
| S | M | L | XL | |
|---|---|---|---|---|
| Reach | 405 mm | 437 mm | 468 mm | 500 mm |
| Stack | 610 mm | 617 mm | 637 mm | 648 mm |
| Seattube | 413 mm | 444 mm | 473 mm | 509 mm |
| Chainstay | 445 mm | 445 mm | 445 mm | 445 mm |
| Headtube Angle | 66° | 66° | 66° | 66° |
| Seattube Angle (eff) | 74° | 74° | 74° | 74° |
| Wheelbase | 1172 mm | 1198 mm | 1236 mm | 1270 mm |
| Headtube | 110 mm | 110 mm | 130 mm | 140 mm |
| BB Height | 350 mm | 350 mm | 350 mm | 350 mm |
| Standover | 750 mm | 750 mm | 750 mm | 750 mm |
| Front Centre | 727 mm* | 753 mm* | 791 mm* | 825 mm* |
| FC:RC | 1.63 | 1.69 | 1.78 | 1.85 |
Trims · 3
Core €7,499 | Pro €8,999 | Ultra €11,999 | |
|---|---|---|---|
| Motor | Brose Drive S Mag · 90 Nm · all trims | ||
| Battery | Rotwild IPU750 750Wh · 750 Wh · all trims | ||
| Travel F/R | 150/152 mm · all trims | ||
| Frame | Full carbon with aluminium inserts in structural areas | Full carbon with aluminium inserts in structural areas | Full carbon, high-modulus fibre; carbon linkage and shock yoke |
| Fork | Fox 36 Float Performance, 150 mm, FIT GRIP 3-pos micro adjust, E-Bike+, OD crown, 44 mm offset | Fox 36 Float Performance, 150 mm, FIT GRIP 3-pos micro adjust, E-Bike+, OD crown, 44 mm offset | Fox 36 Float Factory Kashima, 150 mm, FIT4 3-pos adjust, E-Bike+, OD crown, 44 mm offset |
| Shock | Fox Float X Performance, 205x60 mm trunnion, 2-pos, EVOL LV | Fox Float X Performance, 205x60 mm trunnion, 2-pos, EVOL LV | Fox Float X Factory Kashima, 205x60 mm trunnion, 3-pos adjust, EVOL LV |
| Headset | Acros RW750 1.5 headset with Blocklock · all trims | ||
| Stem | Rotwild S140 AL7075, 35 mm clamp, 50 mm, MonkeyLink interface · all trims | ||
| Handlebar | Rotwild B280 AL7075, 35 mm clamp, 15 mm rise, 780 mm | Rotwild B220 Carbon, 35 mm clamp, 15 mm rise, 780 mm | Rotwild B220 Carbon, 35 mm clamp, 15 mm rise, 780 mm |
| Grips | Ergon GD10 Slim Factory Frozen · all trims | ||
| Saddle | Ergon SM · all trims | ||
| Seatpost | e*thirteen Vario Covert Infinite dropper, individually adjustable up to 260 mm (XL) | Eightpins H01 dropper, 34.9 mm, 25 mm offset, 145 mm (S) / 160 mm (M) / 180 mm (L) / 200 mm (XL) | Eightpins NGS 2 dropper, 34.9 mm, 25 mm offset, 170 mm (S) / 190 mm (M) / 210 mm (L) / 230 mm (XL) |
| Brakes | Magura MT5 HC-W 4-piston, Shiftmix | Shimano XT M8120 4-piston, fin pads | Shimano XTR M9120 4-piston, fin pads |
| Rear derailleur | Shimano XT M8100 12-speed | Shimano XT M8100 12-speed | Shimano XTR M9100 12-speed |
| Crank | e*thirteen Plus, 160 mm (S) / 165 mm (M, L) / 170 mm (XL) | e*thirteen Plus, 160 mm (S) / 165 mm (M, L) / 170 mm (XL) | e*thirteen Race Carbon, 160 mm (S) / 165 mm (M, L) / 170 mm (XL) |
| Shifters | Shimano XT I-Spec EV | Shimano XT I-Spec EV | Shimano XTR I-Spec EV |
| Cassette | Shimano CS-M6100 10-51T 12-speed | Shimano CS-M7100 10-51T 12-speed | Shimano XTR M9100 10-51T 12-speed |
| Drivetrain | Shimano XT M8100 12-speed; e*thirteen Plus, 160 mm (S) / 165 mm (M, L) / 170 mm (XL); Shimano XT I-Spec EV; Shimano CS-M6100 10-51T 12-speed | Shimano XT M8100 12-speed; e*thirteen Plus, 160 mm (S) / 165 mm (M, L) / 170 mm (XL); Shimano XT I-Spec EV; Shimano CS-M7100 10-51T 12-speed | Shimano XTR M9100 12-speed; e*thirteen Race Carbon, 160 mm (S) / 165 mm (M, L) / 170 mm (XL); Shimano XTR I-Spec EV; Shimano XTR M9100 10-51T 12-speed |
| Wheels | DT Swiss H 1900 Spline 30, Ratchet LN 18, 6-bolt | DT Swiss HX 1501 Spline One 30, Ratchet EXP OS, Centerlock | DT Swiss HXC 1501 Spline One 30 carbon, Ratchet EXP OS, Centerlock |
| Tyres | Schwalbe Magic Mary / Hans Dampf Evo, Super Ground, Trail TLE Soft, 29x2.40 / 27.5x2.60 · all trims | ||
| Price | €7,499 | €8,999 | €11,999 |
